Kaolin Powder grinding and separating machine in Qingdao Quality Choice

Name: Kaolin Powder grinding and separating machine in Qingdao Quality Choice
Brand: shina
Price: USD $5800.00 - 5800.00 / Set

FOB Price

USD $5800.00 - $5800.00 / Set

1 Set(Min.Order)

Supply Ability 23 Set / Sets per Month
Port qingdao
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Gravity Separator	Production Capacity:	90%
Place of Origin:	Shandong, China	Brand Name:	shina	Model Number:	ATP
Voltage:	Clients Local Standard	Power(W):	88888	Dimension(LWH):	Size
Weight:	different	Certification:	ISO9001 CE BV SGS	Warranty:	18 Months
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Principle:

AIR CLASSIFIER ATP SERIES has been developed especially for ultra fine cut points. The main point of its development was to achieve a high fineness of the end product. A good sharpness, high efficiency and low specific energy consumption with highest fines output were the guideline for this target. We could achieve these criteria by optimizing the dynamic of air flow, the material resistance and the multi-wheel concept. With this series we can offer an air classifier to meet even the most exciting product requirements. The classifying wheel is especially developed for highest strength during production. The wheel is placed in a horizontal position driven by belt. Also a wear protected wheel can be supplied.

Feature:

- 1-6 rotors in a classifier chamber

- Direct driven rotors

- High speed drive system

- Adjustable of cut point by variable rotor speed via frequency converter

- Fine classification with high performance by special wheel design

- Feed from bottom with main air stream for high feed rates

- Best sharpness by most effective coarse classifying zone

- Construction material can be mild steel, stainless steel or wear protected

Technical Data

ATP series Air Classifier with One wheel/Rotor:

Type Parameter	ATP315	ATP400	ATP500	ATP570	ATP750
Product Fineness (D97: um)	3~150	4~150	5~150	8~150	10~150
Output Capacity (t/h)	1.5~3	2~5	3~6	4~7	5~12
Powder (KW)	11	15	22	30	37
Airflow (m3/h)	3000	4800	7200	9000	16000

ATP series Air Classifier with Multi wheel/Rotor:

Parameter Type	Product Fineness (D97: um)	Output Capacity (t/h)	Powder (KW)	Airflow (m3/h)
ATP315/3	3~150	3~8	11x3	9000
ATP315/4	3~150	4~12	11x4	12000
ATP315/6	3~150	6~18	11x6	18000
ATP400/3	4~150	4~15	15x3	15000
ATP400/4	4~150	6~20	15x4	20000
ATP400/6	4~150	8~25	15x6	28000
ATP500/3	5~150	7~22	22x3	22000
ATP500/4	5~150	9~28	22x4	30000
ATP500/6	5~150	12~35	22x6	45000

Note: 1. Capacity depends on material properties and final product fineness
2. Product Fineness is adjustable according to different technical data

Customer Referrence

Name: Air Classifier IMC 200 Production Line

Name of feed material: Rare Earth Polishing Powder

Place: Taian city, Shandong Province, China

Installation Time: June. 2009

Name: Air Classifier IMC315/4

Name of feed material: CaCO₃

Place: Anhui Province, China

Installation Time: Dec. 2010

Name: Air Classifier ATP315

Name of feed material: KaoLin
Place: Malaysia
Installation Time: Oct. 2014

Name: Air Classifier ITC450

Name of feed material: Silica
Place: Ukraine
Installation Time: Dec. 2015

Name: Air Classifier IMC260

Name of feed material: Chemical etc
Place: Guangxi , China
Installation Time: Jan.. 2013

Name: Air Classifier ATP400

Name of feed material: Silica
Place: Korea
Installation Time: March. 2015

- Can't find customers reference in your country?

- Can't find customer reference same as your project/feed material?

Now! Please do feel free to contact us.

Our experienced and kind sales-person will reply you with more information within 24 hours!

Otherwise,

Click and fill in under form, sending us one inquiry.

We will reply you within 24 hours with detailed proposal offer.

After-sales Service

After-sales Service:

We have one good after-sales team.

All the engineers have experience more than 5~10 years and can speak very good English.

We supply services for engineering, consultancy, supervision erection and commissioning with test run.

We will reply customers within 24 hours as soon as possible to solve problems.

Quality Guarantee Period:

All the machines will be checked carefully and empty running before delivery.

If the machine is damaged because of the design, manufacture or the materials of the machine within one and half year, we will repair it or change the parts for free;

If the machine is damaged because of man-made cause or outside the warranty period, we will also provide warmly service, and we only charge the cost of parts if necessary.

Customer Reference

Customers Say

“I do rear earth polishing powder business for more than 20 years. After I visit Qingdao shina factory, and checking the quality of air jet mill and other machines, I made decision to buy from Qingdao shina. Now, in my workshop, there is one set of air jet mill QWJ10 production line and one set of air classifier IMC 100 production line. Both of them are running very well. Thank Qingdao shina for its good quality and service. ”

--- Mr. Yu from taian, Shandong, China

“Good design, professional technology, great service, Qingdao shina—not one big factory on factory size, but its powerful on technology is really strong. Wish we can cooperate with each other again.”

--- Mrs. Mistakidou from Greece

“I bought many machines from China. But Qingdao shina really gives me great impression. They use good materials for each parts, they won't delete each small “machinery process”, like fire-treatment for some parts to make sure its quality. I have bought one unit of air classifier ATP315 for GCC powder and draft fan, one set of air jet mill QWJ20 production line for talc powder. I recommend QINGDAO SHINA.”

--- Mr. Muhammad from Pakistan

FAQ

1. Why choose QINGDAO SHINA as supplier?
A: QINGDAO SHINA has a perfect team with more than 20 years experience. Technology of QINGDAO SHINA is original from Germany. What customers get from QINGDAO SHINA is not only one set of machine, but together with know-how.

2. What should I do if I want to start a new project or extent production, but I have no idea what

should I do at the beginning?
A: Please send email to QINGDAO SHINA and tell QINGDAO SHINA your situation of the project, QINGDAO SHINA will supply one feasibility study report together with detailed proposal and technical suggestions only for your project.

3. How about the quality of machine manufactured by QINGDAO SHINA?
A: QINGDAO SHINA business concept is: "Start a career with essence, win through high quality". QINGDAO SHINA follows the principle of “quality is most important” when manufacturing each machine. Besides, QINGDAO SHINA decides to lengthen quality guarantee of each machine or production line to 1.5 years so that customers can use machine without worry.

4. How about the after-sales service of QINGDAO SHINA?
A: QINGDAO SHINA has a good after-sales service team, all the engineers in the team has more than 10 years experience. QINGDAO SHINA can promise that after the machine arriving at customer' s factory, we will arrange our engineer in time accordingly to make installation. Commissioning and test run. QINGDAO SHINA’s customer service concept is: customers are always the first!

5. How can I start the machine when getting machine?
A: QINGDAO SHINA will arrange engineers with rich experiences to customer’s factory for installation, commissioning and test run. After then, engineers will make training for workers about how to start machine or production line until workers can start machine very good alone.

6. If there are some problems or questions during running machine or production line, what should I do?
A: Please call QINGDAO SHINA in time if you have any questions during production. QINGDAO SHINA will reply customers in time to make sure the production won’t be delayed.

How to get one detailed proposal offer?

If you want to get more information about our machine and one detailed proposal offer for your project, please send email or inquiry with the following information to us now, we will reply you within 24 hours.

1. what is the name and size of feed material?

2. what is the capacity do you request?

3. what is the fineness of final product?

4. other request?
