85T Good Vertical LSR Injection Molding Machine V85R2-LSR

Name: 85T Good Vertical LSR Injection Molding Machine V85R2-LSR
Brand: Qianke
SKU: 111078291

US$ 1,500 - 80,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Preform Injection

Style:

Vertical

Zhongshan Yatai Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhongshan

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Preform Injection

Style Vertical

Brand Name Qianke

Model Number V85R2-LSR

Place of Origin Guangdong, China

Plastic Type Thermoplastic

Automatic Yes

Injection Weight 223cm3

Injection Rate 107mm/s

Clamping Force 85Tf, 35-200Ton

Opening Stroke 250mm

Certification CE

After-sales Service Provided Overseas service center available

Specifications

1.Clamping force 35-200tons
2.Vertical clamping,Vertical injection,easy to insert
3.Famous brand in each parts.
4.Yuken,Omron

1,Specifications

			Unit	V85R2-LSR
Injection Unit	Screw Diameter		mm	40	45
	Theoretical Injection Volume		cm3	176	223
	Max.Injection Pressure		Mpa(kgf/cm2)	146(1492)	115(1176)
	Injection Rate		cm3/s	134	170
	Injection Speed		mm/s	107
	Screw Speed Rotation		r.p.m	0-300
	Nozzle Out From Platens		mm	≥45
Clamping Unit	Clamping Force		KN(tf)	833(85)
	Clamping Stroke		mm	250
	Min.Mold Thickness		mm	170(270)
	Max.Opening		mm	420(520)
	Distance Between Tie Bars		mm	500*385	658*335	---
	Max.Mould Size		mm	550*470	500*475	340*340
	Platen/Slide Size		mm	620*490	1135*495	980
	Ejector Distance		mm	75	75	75
	Ejector Force		KN(tf)	26.5(2.7	26.5(2.7)	45(4.6)
Others	System Pressure		Mpa(kgf/cm2)	13.7(140)	13.7(140)	13.7(140)
	Oil Tank Capacity		L	280	280	310
	Electric Power		KW(HP)	15(20)	15(20)	15(20)
	Machine Dimensions	L*W	mm	2140*1410	2090*1700	2145*1772
		H	mm	2736(3456)	2730(3470)	2760(3500)
	Machine Weight		tf	3.35	3.7	4.3
