2-phase Hybrid Stepper/stepping Motor (DM28xxE)
US$ 19 - 25
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
Leetro
Model Number:
DM28xxE
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2-phase Hybrid Stepper Motor, DM2xxEUS$ 19 - 25MOQ: 1 Piece -
1.2 Three-phase Hybrid Stepper Motor (DM313xx)US$ 147 - 255MOQ: 1 Piece
-
1.2 Three-phase Hybrid Stepper Motor (DM39xxE)US$ 50 - 66MOQ: 1 Piece
-
DM36x, 3-phase Hybrid Stepper MotorUS$ 15 - 28MOQ: 1 Piece
-
Cost Effective and Reliable DM86xxE, 2-phase Hybrid Stepper/stepping MotorUS$ 70 - 80MOQ: 1 Piece
Place of Origin
Sichuan, China
Brand Name
Leetro
Model Number
DM28xxE
Phase
2
Type
Hybrid
Step Angle(degrees)
1.8
Holding Torque
0.06-0.095
Current / Phase
0.67
Item |
Specifications |
Step Angle |
1.8 |
Step Angle Accuracy |
±5% (full step, no load) |
Resistance Accuracy |
±10% |
Inductance Accuracy |
±20% |
Temperature Rise |
80C Max. (rated current, 2 phase on) |
Ambient Temperature |
-20~+50C |
Insulation Resistance |
100MΩMin., 500VDC |
Dielectric Strength |
500VAC for one minute |
Shaft Radial Play |
0.02Max. (450 g-load) |
Shaft Axial Play |
0.08Max. (450 g-load) |
Max. radial force |
28N (20mm from the flange) |
Max. axial force |
10N |
| Model | Rated | Current | Resistance | Inductance | Holding | Rotor | Weight | Length |
| Voltage | /Phase | /Phase | /Phase | Torque | Inertia | (kg) | (mm) | |
| (V) | (A) | (Ω) | (mH) | (N×m) | (g×cm2) | |||
| DM2832E | 3.8 | 0.67 | 5.6 | 3.4 | 0.06 | 9 | 0.11 | 31.5 |
| DM2845E | 4.56 | 0.67 | 6.8 | 4.9 | 0.095 | 12 | 0.14 | 44.5 |
| Model | Leetro Driver | ||
| DM2832E | DMD402A | ||
| DM2845E | |||
Packaging & Shipping
DHL, TNT, FedEx air express
sea shipping availble under request
