Home > Electrical & Electronics > Electric Motor > Stepper Motor > 2-phase Hybrid Stepper/stepping Motor (DM35xxE)
2-phase Hybrid Stepper/stepping Motor (DM35xxE)
US$ 12 - 22
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
Leetro
Model Number:
DM35xxE
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2-phase Hybrid Stepper/stepping Motor (DM28xxE)US$ 19 - 25MOQ: 1 Piece -
2-phase Hybrid Stepper Motor, DM2xxEUS$ 19 - 25MOQ: 1 Piece
-
1.2 Three-phase Hybrid Stepper Motor (DM313xx)US$ 147 - 255MOQ: 1 Piece
-
1.2 Three-phase Hybrid Stepper Motor (DM39xxE)US$ 50 - 66MOQ: 1 Piece
-
DM36x, 3-phase Hybrid Stepper MotorUS$ 15 - 28MOQ: 1 Piece
Place of Origin
Sichuan, China
Brand Name
Leetro
Model Number
DM35xxE
Phase
2
Type
Hybrid
Certification
ISO
Step Angle(degrees)
1.8
Holding Torque
0.10-0.14
Current / Phase
0.5-1.0
| Item | Specifications | |||
| Step Angle | 1.8° | |||
| Step Angle Accuracy | ±5% (full step, no load) | |||
| Resistance Accuracy | ±10% | |||
| Inductance Accuracy | ±20% | |||
| Temperature Rise | 80C Max. (rated current, 2 phase on) | |||
| Ambient Temperature | -20~+50C | |||
| Insulation Resistance | 100MΩMin., 500VDC. | |||
| Dielectric Strength | 500VAC for one minute | |||
| Shaft Radial Play | 0.02Max. (450 g-load) | |||
| Shaft Axial Play | 0.08Max. (450 g-load) | |||
| Max. radial force | 28N (20mm from the flange) | |||
| Max. axial force | 10N | |||
| Model | Rated | Current | Resistance | Inductance | Holding | Rotor | Weight | Length |
| Voltage | /Phase | /Phase | /Phase | Torque | Inertia | (kg) | (mm) | |
| (V) | (A) | (Ω) | (mH) | (Nm) | (gcm2) | |||
| DM3528E | 10 | 0.5 | 20 | 18 | 0.10 | 11 | 0.14 | 28 |
| DM3536E | 2.7 | 1.0 | 2.7 | 4.3 | 0.14 | 14 | 0.18 | 36 |
| Model | Leetro Driver | ||
| DM3528E | DMD402A | ||
| DM3536E | |||
Packaging & Shipping
TNT, DHL, FedEx air express
Our Services
12-month product warranty
