Most Popular Stand-alone Dispensing Robot Controller

BCD3000 is designed with the open-loop motion control technology for the dispensing robot and dripping machine (up to 4-axis). It is Leetro 4^th generation. Based on DSP and FPGA technology, the advanced velocity look-ahead and trajectory blending algorithm ensure the velocity invariableness and transition smoothness between any two-trajectory segments during the high speed X-Y-Z continuous trajectory motion. The supplementary software LOGOSHOP offers powerful functions, such as 3D rotate, array and dynamic reading.

Applications:

Over 8-year experience in dispensing robot machines for the industries of audio, electronics, LED and others, open-loop motion control system, normally one nozzle/colour.

Inquiry for dripping (micro-injection) motion control system (normally 8-24 nozzle/colour), please quote “DSP3000M” to overseas(at)

• Stand-alone
• Both servo and stepper motor supported
• 3D circular constant motion supported by Trapezoidal Acc/Dec, Look-ahead and Micro-segment Interpolation
• Max. pulse output frequency 500KHz
• High precision control, +/-0.5 pulse
• Support the 4^th axis in rotation function
• High speed 2GB storage
• 920kb/s industrial RS485 bus
• Store up to 999 files, 65535 dots in each file
• Firmware updated by USB flash drive

Supplementary Software, LOGOSHOP

l      Supports file format, NC, AI, DXF, JPG and BMP

l      3D dynamic reading, rotating and arraying

l      Read and transfer a over-10MB file

l      Auto-path and user-define patch

Software Environment

BCD3000 does not support connecting PC

LOGOSHOP is the supplementary software

LOGOSHOP-saved job file is transferred by the flash memory disk to the teaching pendant

Working Environment

Temperature: 0-60℃

Humidity: 5-90%, non condensing

Power

24VDC, 2A

 TNT, DHL, FedEx air Express

 12-month product warranty
