This Software is for Leetro's laser-dedicated controllers exclusively
LaserCut software developed by Leetro Automation Co., Ltd. It is applied to laser engraving and cutting system based on MPC03, MPC6515 or MPC6535.
Main features:
* Seamless connection with CorelDraw and AutoCAD makes the operation much easier.
* Supports data formats such as AI, BMP, PLT, DXF, DST (Tajima Software).
* After graphics & image data being called in, the system will carry out simple makeup and edit (such as zooming, rotating, reproducing and so on)
* The software can hierarchically output data and easily set the output power, output speed and output mode (engrave, cut, and so on) and automatically save the defined parameters of every layer.
* The software can engrave the image, scribe, cut and engrave the vector diagram and set engraving precision.
* The software supports array output and can automatically distribute the array to the entire workbench. The software can also display output effect through analog output. The origin location can be defined at random to facilitate processing.
* Pause and Continue are available during output and all output control operations can be directly connected to the operational control panel of devices for easy operation.
* The software provides frame-tracing function during output so as to easily find the discharge location.
Engraving speed can reach 1500mm/s, curve cutting speed can reach 500mm/s and engraving precision can reach 0.1mm.
* 360 degree slope engraving. The slope can be freely set and there is no limitation of speed (subject to the laser processing depth).
* High processing speed of large data & graphics. Data of 15M less can be processed for an instant.
* Constant laser processing strength during high-speed cutting ensures consistent processing depth.
* Optimized Cutting path. Customers are provided with various path optimization methods.
* Derivate lines can be introduced when cutting to ensure the smooth and flat cut seaming.
* Unique breakpoint processing function ensures that no rejected product will be produced even when power is suddenly cut.
Outstanding features compared with laser engraving like products:
* Advanced Position Compare Output Iron out the deviation problem in speedy engraving. The engraving speed is 90m/min, leading the like products.
* Distinct Look-Ahead Algorithm And Track-Fit Algorithm highly enhance the operating efficiency. Speed for cutting circles reaches 30 m/min, leading the laser processing industry.
* Advanced Synchronous Tracking Control Ensure the synchronous changes of the laser power and the speed of laser head's moving.
* Advanced PWM (Pulse-Width Modulated) Control Implement 360 degree slope engraving easily, increase the real-time capability in adjusting the laser power.
* No distortion in speedy cutting roundlet
DHL, TNT, FedEx air express
12-month product warranty
