1,Our Industry Advantage:
(1) PP/PE/PVC/PC/AS/PET/PET-G;
(2) Products of volume: 30ml-1000L;
(3) 1 year warranty;
(4) 20 years experience
(5) After-sales Service Provided: Engineers available to service machinery overseas
(6) All machine for Hydraulic system
(7) Many patent certificates
(8) More than 1000pcs different samples
(5)Screw diameter :50mm;55mm,65mm,70mm,80mm,90mm,100mm,120mm,130mm etc.
(6) L/D: 23:1; 25:1; 28:1, 30:1
(7) Sales to more than 30 countries
(8) From 1-3 layers
shampoo bottle making machine in huangyan taizhou from YF-55
2, YF-55 shampoo bottle making machine in huangyan taizhou
shampoo bottle
3, Main characteristic
(1) Double process with single-four Die-heads
(2) Max. 2L
(3) Hydraulic system
(4) Max. 3500pcs/h(for 50ml)
(5) 220-380V; 3 phase; 50-60HZ (Custom Made)
(6) 55mm Diameter of screw; L/D 23:1
(7) 1 Year warranty
4, Technical specification
Model |
YF- 55 |
||
Suitable Materials |
PE, PP, AS,PVC,PET-G |
||
Theoretical Output |
Depend on bottle design |
Max. 3300BPH(for 50ml) |
|
Max. Product Volume |
1cavity/2cavity/4cavity |
2000ML/500ml/200ml |
|
Die Head Amount |
Piece |
1/2/4 |
|
Work Station Amount |
Piece |
2 |
|
Extrusion Unit |
Screw Diameter |
55mm |
|
Screw L/D Ratio |
25:1 L/D |
||
Screw Speed |
10-60 r/min |
||
Plasticizing Capacity |
40kg/h |
||
Mould Unit |
1 Cavity 2Sets;2cavity2sets;4cavity2sets |
1 Cavity 2Sets;2cavity2sets;4cavity2sets |
|
Max. Bottle Diameter |
80mm |
||
Mould Thickness |
70~130mm |
||
Mold Board Stroke |
130mm |
||
Clamping Force |
50 KN |
||
Power Unit |
Electrical Source |
220-380V,3phase 50/60Hz |
|
Heating Power |
7 KW |
||
Motor |
7.5 KW |
||
Average Energy Consumption |
10 KW |
||
Air Pressure |
0.7 MPa |
||
Machine Size |
L*W*H |
2800*1850*2300mm |
|
Machine Weight |
2.5T |
||
Auxiliary Equipments |
Low Pressure Air Compressor 1 Set (requisite) |
1.0m3 /1.0Mpa/15KW |
|
crush machine 1set |
50 |
||
mixing machine 1 set |
100kg |
||
5, Parts and Brand for your reference
Item |
Brand |
Country |
Oil Pump |
YUKEN |
Japan |
Control switch |
MITSUBISHI PLC |
Japan |
The contactor |
Schneider Electric |
France |
Reversing valve |
DUPLOMATIC |
Italy |
Proportioning valve |
SMC |
Japan |
oil valve |
YUKEN |
Japan |
Touch screen |
PROFACE |
Japan |
PLC |
MITSUBISHI |
Japan |
Inverter |
INVT |
Taiwan |
Temperature |
OMRON |
Japan |
Valve |
ATOS |
Italy |
6, Main part pictures
Gate of Factory
Sample Room
Meeting Room
Reception Room
1, Our samples and machines
Extrusion blow moulding machine
PET blow moulding machine
Samples
