automatic coffee powder pouch packing machines manufacturer
Scope of application
Powder Packing Machine
Model |
Packing Application |
CB-3220 |
Suitable for granule products like peanut, coffee, small biscuit; powder products and chips. |
CB-4230 |
Suitable for granule and fluent powder such as sugar, salt, rice, coffee, sesame, forage, MSG |
CB-5240 |
Suitable for Peanut, coffee, small biscuit, granule, puffy food, corn, rice etc |
CB-6848 |
Suitable for many kinds of powder products like four, cocoa, milk powder and chemical powders, etc. |
Sample display
Functional Description
Powder Packing Machine
1. PLC control with stable,reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing, cutting , finished in one operation.
2. Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
3. Film-pulling with vacuum double belt: less pulling resistance, bag is formed in good shape with better appearance, belt is resistant to be worn-out.
4. Double servo control, high precision orientation, size more nicety.
5. External film releasing mechanism: simpler and easier installation of packing film.
6. Adjustment of bag deviation just needed to be control the touch screen. Operation is very simple .
7. Close down type mechanism , defending powder into inside of machine.
Technical Specifications
Model |
CB-3220 |
CB-4230 |
CB-5240 |
CB-6848 |
Speed |
Max 80bags /min |
Max 60bags /min |
Max 50bags /min |
|
|
Width:50-500ml |
Width 150-1200 ml |
width:50-300ml |
Width:80-350ml |
Bag size |
L (50-200) ×W (40-150) mm |
L (80-300) ×W (50-200) mm |
L (80-400) × W (80-250) mm |
(100-480) × (180-320)mm ( L × W ) |
Width of film |
320mm |
420mm |
520mm |
680mm |
Rang |
Max500ml |
Max 1300ml |
Max 3000ml |
Max 6000ml |
Power |
220v 2kw |
220v 2.2kw 50-60HZ |
220v 4kw 50-60HZ |
220v 5kw 50-60HZ |
Film |
POPP/CPP,POPP/PE,BOPP/PE,PET/AL/PE,NY/PE |
|||
Gas need |
0.6Mpa 0.25m3/min |
0.65Mpa 0.3m3/min |
0.65Mpa 0.4m3/min |
0.65Mpa 0.4m3/min |
Size |
L 900 * W 680 * H 1960 mm |
L 1320 * W 950 * H 1360 mm |
L 1150 * W 1795 * H 11650 mm |
L1780mm*W1350mm*H1950mm |
Weight |
180KG |
540KG |
600KG |
900KG |
Optional External Device:
Customer Sevices
1) Free consultation service before, during, and after sales;
2) Free project planning and design services;
3) Free debugging of equipment until everything is functional;
4) Free management of equipments' long distance shipping;
5) Free training of equipment maintenance and operating personally;
6) Free new production techniques and formulas;
7) Provide 1 year complete warrantee and lifetime maintenance service
reliable equipment.
