Scope of application:
Suitable for:milk powder,soya bean powder,sesame paste,coffee powder,medicine powder etc.
Functional description:
1.The machine is controlled by double SCM (single chip) system and a large LCD (115*64 mm) in English display.
3.Special and particular intelligence protection take the machine to auto stop to get the protection and display the fail information when the machine fail in temperature control, color mark hunt control and film finish.
4.Four intelligent temperature controllers. When the heating part or testing part fail to take the sealing temperature over 15 degree of the setting temperature, the machine will stop and display “heat over”. So you can make the wastage to the least.
5.The bag length is controlled by electronic photo switch. The bag length will be cut accurately. When the photo errs, the machine will stop and display “photo errs”.
6.When the packaging film is empty or broken, the machine will stop and display “film end”.
7.The intelligent counter: you can set the counter to a data you need, the machine will stop and take alarm when reach the data you set.
8.The working is stable, easy to use, high yield and low wastage.
| Model | CB-220P | CB-388P |
| Bag size | L (40-150) ×W (30-100) mm | L (50-200) ×W (40-150) mm |
| Packing speed | 40-60 bags/min | 40-100 bags/min |
| Measuring range | 1-100 ml | 50-500 ml |
| Max width of film roll | 320 mm | 320 mm |
| Power requirement | 380/220V, 50HZ, 790/1000W | 380/220V, 50HZ, 2000W |
| Machine size | L 700* W 580 * H 1550 mm | L1350* W 580 * H 1700 mm |
| Machine weight | 200 KG | 250 KG |
| Sealing type: | 3-side sealing ,4 side sealing | back sealing |
| Applied for | milk power,soyabean powder ,sesame paste,coffe powder ,medicine powder,etc. | |
Origin of each components:
Touch screen: Siemens / Germany Inverter: Schneider / French
PLC controller: Siemens / Germany Module: Siemens / Germany
Date printer: Dikai / Shanghai Motor: Tongtai / Kunlun
Photo-sensor: SICK / Germany Relay: Omron / Japan
Switch series: Schneider / French Solid phase: Schneider / French
CHUANGLIBAO has been an professional manufacturer of packing machine since 1998. We have strong research and development team, research and innovate is our aim and market is our guiding. We can research 2-3 new machines each year, and we spent more than USD $50000 for exhibition each year, we have been to Turkey, Indonesia, Malaysia, Dubai and so on, so we think we should have enough experience to help u more.
We are the second biggest packing machine supplier in China, our production is 50 sets per month, we can delivery you machine within 25 days as soon as we got your deposit. And we can send our engineer and master to your factory for machine service if you need, so we can help you in time.
- Consultation service before, during, and after sales;
- Project planning and design services;
- Debugging of equipment until everything is functional;
- Management of equipments' long distance shipping;
- Training of equipment maintenance and operating personally;
- New production techniques and formulas;
- Provide 1 year complete warrantee and lifetime maintenance service.
