New Cheap 1.25T MF/IF Scrap Steel Melting Furnace

Name: New Cheap 1.25T MF/IF Scrap Steel Melting Furnace
Brand: YIPHEE
Availability: InStock

FOB Price

USD $1,000 - $90,000 / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port guangzhou
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Induction Furnace
Usage	Melting Furnace	Place of Origin	Guangdong, China
Brand Name	YIPHEE	Model Number	melting furnace
Voltage	380-1000v	Power(W)	800KW
Dimension(LWH)	23m³	Weight	10Ton
Certification	ISO,CE	Warranty	12 Months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

New Cheap 1.25T MF/IF Scrap Steel Melting Furnace

Product Description

1.Using a zero-voltage scanning soft-start mode, in any case may at any time to start or stop, will not have impact on power supply.
2.Rapid melting, the production cost is low; Pollution is small, comply with environmental requirements;
3.A direct effect from the cold furnace melting. Dissolved material will be fully dumped clean. Molten material easy to replace.
4.Power adjustment flexibility. Be able to continuously smooth adjustment. Temperature uniformity can be easily controlled. Oxidation burning less. Metal components evenly.
5.Furnace shell using cast aluminum or steel structure, small footprint; Furnace flip dump convenience, according to the need to use electric, manual, hydraulic tilting furnace and other means.
6.Designed to automatically adjust angle of inverter circuit that can automatically adjust the load impedance match, without adjustment of capacitance compensation and always run the equipment in good working condition; Power supply system diagnostic error function, easy maintenance.
7. We will customize the furnace according to your request.

The main products

1. aluminum bar heating furnace;heating furnace of copper rods;stainless steel and other metal bar heating.
2. Intermediate frequency melting electric furnace; induction furnace, medium frequency induction furnace;copper melting furnace;cast iron melting furnace;intermediate frequency melting furnace of aluminum; medium frequency induction melting nickel;experimental electric furnace;noble metal smelting furnace;small smelting furnace;heat treatment equipment;intermediate frequency induction pipe bending equipment;medium frequency induction diathermy apparatus.
3.We will customize the furnace according to your request.

Capacity kg	Powerkw	input voltage v	Frequency of Input Current hz	Rated input Current A	Transformer Capacity KVA	output voltage V	output frequency KHZ	melting time MIN	Energy Consumption Kw.h/T	Water Cooling T/h	Input Water Pressure MPa	Volume M3	Weight kg
10~50kg	50	380	50/60	80	60	750	2.5	20-60	900	3	0.2	1.2	350
100kg	100	380	50/60	160	120	750	1000	20-60	850	5	0.2	6	1500
150kg	100	380	50/60	160	120	750	1000	30-70	850	5	0.2	6.5	1600
200kg	120	380	50/60	192	150	750	1000	30-70	800	7	0.2	7.5	1700
250kg	130	380	50/60	208	150	750	1000	30-70	800	7	0.2	8.5	1800
350kg	180	380	50/60	288	200	750	1000	30-70	750	8	0.2	9	2000
500kg	250	380	50/60	400	315	750	1000	30-70	700	10	0.2	9.5	2300
600kg	350	380	50/60	560	400	750	1000	40-80	700	11	0.2	11	2500
750kg	450	380	50/60	720	500	1500	1000	40-80	650	15	0.2	12	3800
1000kg	600	380 380v-2	50/60	960 480	600	1500	0.8	50-90	620	18	0.2	13	4500
1250kg	800	380 380v-2	50/60	1280 640	800	1500	0.8	50-90	600	20	0.2	14	5000
1500kg	1000	380 380v-2	50/60	1600 800	1250	1500	0.8	50-90	600	25	0.2	15	5500
2000kg	1250	660 380v-2	50/60	1120 1000	1500	2500	0.7	50-90	580	28	0.2	17	6000
3000kg	1500	660 380v-2	50/60	1350 1200	1800	2500	0.7	60-100	570	35	0.2	20	7000
5000kg	2500	1000 660v-2	50/60	2000 1120	3000	3000	0.5	60-100	560	43	0.2	23	8500
6000kg	4000	1000	50/60		4400	4000	0.5	60-100	560	52	0.2	26	10000
8000kg	5000	1000	50/60		5000	5000	0.5	60-100	560	62	0.2	30	14000

Our company

Yiphee Electric Crucible Furnace passed ISO international quality system certification and EU CE Certification,and induction melting furnace for iron have been sold to many contries,such as Europe, Belarus, Russia, Kosovo, Portugal, Africa, Libya, Zambia, Zimbabwe, South America, Ecuador, Peru, Brazil, North America, Asia, Hong Kong, Vietnam, Malaysia, Indonesia, Myanmar, Saudi Arabia, Lebanon, Bahrain, Tajikistan, Uzbekistan, North Korea, Poland, Iran,Colombia, Australia,Iran,etc.
