10HP cheap new tractors
- 50000 Set / Sets per Month
- QINGDAO
Product Details
Condition: | New | Type: | Walking Tractor | By wheel: | 2WD |
Usage: | Farm Tractor | Drive Type: | Gear Drive | Power(W): | 7000 |
Certificate: | Other, iso9001 | Brand Name: | FENGLI | Model Number: | 101B |
Place of Origin: | Shandong, China | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
FL101 walking tractorpull and drive.
the diesel: 190,but optional
compact construction
cultivate and transport
This is 10HP walking tractor.
We are Shandong Agricultural Equipment,Co.,Ltd. We are glad to help you. And customers around the world are all welcome, anytime. We hope our factory and customers, you, will achieve developments always, together.
1. the overall unit model: model 101B
type: both traction and driving
overall dimensions(L×W×H):2170×910×1160mm
wheel tread: 680~740mm( stepless adjustable)
mini-ground clearance:210mm
mini-working weight:340kg
transmission box: has main and subsidiary transmissions, 6 forward gears and 2 reverse, full power sliding gear transmission, (3+1)×2 composition style round column gear drive.
Connection of engine and transmission system:2 B188 triangle belts.
Number of stalls(forward/reverse): 6/2.
Every stall’s rated speed:
Stalls | 1 | 2 | 3 | 4 | 5 | 6 | Reverse 1 | Reverse 2 |
Speed(kw/h) | 2.52 | 2.98 | 3.12 | 9.3 | 16.37 | 24.49 | 1.93 | 6 |
Traction(N) | 1600 | 1600 | 1600 | 1600 | 1616 | 956 | / | / |
Connection of engine and clutch: belt transmission
Starter: hand cranking
Open size of traction box:95mm
2.engine trademark and model: JIANGDONG ZH190T
Style: horizontal, single cylinder, four strokes, water-cooled.
Company’s name: Yancheng Xingdong Machinery CO., Ltd.
Number of cylinder : 1 cylinder .
Cylinder diameter×stroke:90×90mm .
Replacement: 0.573L
Compression ratio: 18:1
Rated power: 7kw
Rated rotary speed: 2300r/min
Style and model of fuel injection pump: fork type, BF1A80Z03
Style and model of air filter: paper-oil bath steel mesh filter
Cooling system: evaporative cooling
3.style of headlamp: 190H3
4.model of fuel tank: R185-11100
Capacity: 7.4L
5.about the silencer:
dimensions of eliminating vocal cavity(L×W×H):110×190mm
weight of silencer: 1.5kg
6.transmission system
clutch type: single chip, dry type, normal joining, friction type
transmission box type: composition of mechanical gearbox 7.travelling system:
model of tyre(drive wheel):6.00-12
tyre pressure(driving wheel): 120~250kpa
We are happy to help others, and surely we’d like us to cooperate, with you, friends from all over the world. We really want to make our factory better and better. And we will do our best to service you. Let us achive success together.
