15hp cheap chinese walking tractor

Specifications

15hp walking tractor
pull and drive.
the diesel: S1100,but optional
compact construction
cultivate and transport.

This is 15HP walking tractor.

We are Shandong Agricultural Equipment,Co.,Ltd. We are glad to help you. And customers around the world are all welcome, anytime. We hope our factory and customers, you, will achieve developments always, together.

15hp chinese walking tractor

1.the whole tractor

type: both traction and driving

overall dimensions(L×W×H):2170×910×1160mm

wheel tread: 680~740mm( stepless adjustable)

mini-ground clearance:210mm

mini-working weight:340kg

transmission box: has main and subsidiary transmissions, 6 forward gears and 2 reverse, full power sliding gear transmission, (3+1)×2 composition style round column gear drive.

Connection of engine and transmission system:2 B188 triangle belts.

Number of stalls(forward/reverse): 6/2.

Every stall’s rated speed:

Stalls	1	2	3	4	5	6	Reverse 1	Reverse 2
Speed(kw/h)	3.5	6.4	10.4	12.6	21.3	27.7	2.6	7
Traction(N)	1970	1970	1970	1970	1740	1000	/	/

Connection of engine and clutch: belt transmission

Starter: hand cranking , or electric starter , it’s optional.

2.engine   trademark and model: JIANGDONG S1100

Style: horizontal, single cylinder, four strokes, water-cooled.

Company’s name: Yancheng Xingdong Machinery CO., Ltd.

Number of cylinder : 1 cylinder .

Cylinder diameter×stroke:100×115mm .

Replacement: 0.903L

Compression ratio: 17:1

Rated power: 11030W

Rated rotary speed: 2200r/min

Style of fuel injection pump: fork type

Cooling system: evaporative cooling,or water-cooled with condenser, it’s optional

3.style of headlamp: 151

4.model of fuel tank: 185-11100

      Capacity: 9L

5.about the silencer:

weight of silencer: 2kg

6.transmission system

      clutch type: single chip, dry type, normal joining, friction type

      transmission box type: composition of mechanical gearbox 7.travelling system:

model of tyre(drive wheel):6.00-16

tyre pressure(driving wheel): 120~250kpa



We are happy to help others, and surely we’d like us to cooperate, with you, friends from all over the world. We really want to make our factory better and better. And we will do our best to service you. Let us achive success together.
