High speed slurry pump parts/ electric paper pulp pump/ China pump manufacturer
High speed slurry pump parts
Main specification
| Type | flow(M3/h) | height of suction(M) | lift(M) | rotating speed(%) | efficiency(r/min) | dielectric volume concentration(%) | power(kw) |
| 80LXLZ-35-6 | 21-40 | 7-5 | 2.5 | 68 | 1400 | 4-6 | 1.5 |
| 80LXLZ-50-6 | 30-60 | 7-5 | 2.5 | 68 | 1420 | 4-6 | 2.2 |
| 80LXLZ-60-12 | 35-70 | 14-12 | 2.5 | 65 | 140 | 4-6 | 4 |
| 80LXLZ-65-15 | 40-80 | 16-14 | 2.5 | 65 | 1440 | 4-6 | 5.5 |
| 100LXLZ-90-18 | 80-100 | 20-15 | 6 | 60 | 140 | 4-6 | 7.5 |
| 100LXLZ-80-20 | 75-90 | 21-16 | 6 | 60 | 10 | 4-6 | 7.5 |
| 100LXLZ-100-28 | 80-110 | 29-25 | 6 | 60 | 1440 | 4-6 | 11 |
| 100LXLZ-110-20 | 80-120 | 21-18 | 6 | 60 | 140 | 4-6 | 11 |
| 100LXLZ-100-35 | 50-110 | 37-33 | 6 | 60 | 1460 | 4-6 | 15 |
| 100LXLZ-120-40 | 50-130 | 43-37 | 6 | 65 | 1460 | 4-6 | 18.5 |
| 150LXLZ-180-15 | 95-190 | 15-12 | 5 | 60 | 970 | 4-6 | 11 |
| 150LXLZ-210-16 | 160-220 | 20-12 | 6 | 65 | 970 | 4-6 | 15 |
| 150LXLZ-250-25 | 120-260 | 29-20 | 5 | 65 | 1460 | 4-6 | 22 |
| 150LXLZ-250-30 | 150-260 | 37-24 | 5 | 68 | 1460 | 4-6 | 30 |
| 150LXLZ-350-14 | 180-360 | 16-14 | 5 | 75 | 970 | 4-6 | 18.5 |
| 150LXLZ-330-12 | 170-340 | 13-11 | 5 | 75 | 970 | 4-6 | 15 |
| 150LXLZ-420-25 | 230-430 | 27-20 | 5 | 75 | 1470 | 4-6 | 37 |
| 150LXLZ-470-28 | 240-480 | 30-24 | 5 | 75 | 1470 | 4-6 | 45 |
| 150LXLZ-430-32 | 260-520 | 35-28 | 5 | 75 | 1470 | 4-6 | 55 |
| 200LXLZ-250-5 | 150-300 | 6-4 | 5 | 76 | 70 | 4-6 | 5.5 |
| 200LXLZ-330-5 | 240-400 | 6-4 | 5 | 76 | 970 | 4-6 | 5.5 |
| 200LXLZ-700-32 | 550-780 | 37-29 | 5 | 77 | 1480 | 4-6 | 90 |
| 250LXLZ-600-18 | 420-690 | 19-15 | 1.5 | 78 | 980 | 4-6 | 45 |
| 250LXLZ-700-22 | 405-840 | 25-17 | 5 | 76 | 1480 | 4-6 | 75 |
| 250LXLZ-800-25 | 480-960 | 26.5-33 | 5 | 76 | 1480 | 4-6 | 90 |
| 250LXLZ-935-28 | 655-1080 | 30-24 | 1.5 | 75 | 1480 | 4-6 | 110 |
| 300LXLZ-800-18 | 560-920 | 19-16 | 1.5 | 76 | 980 | 4-6 | 75 |
| 300LXLZ-1150-26 | 800-1320 | 28-24 | 1.5 | 78 | 1480 | 4.6 | 132 |
| 350LXLZ-1200-18 | 840-1380 | 20-16 | 3.5 | 79 | 740 | 4-6 | 110 |
| 350LXLZ-1400-25 | 980-1610 | 27-23 | 3.5 | 79 | 980 | 4-6 | 160 |
| 350LXLZ-1500-28 | 1050-1725 | 30-26 | 3.5 | 79 | 980 | 4-6 | 185 |
Foundation drawing
Competitive advantages
1. This pulp pump guaranteed that rotary vacuum pump can start normally in the low temperature of winter. It is applicable to vacuum packaging, vacuum free.
2.Pulp making machine also can be used alone, also can be used as booster pump, diffusion pump, molecular pump and backing pump. Besides, it can be used for vacuum metallurgy, vacuum welding, vacuum impregnation, coating, vacuum drying and chemical pharmaceutical, electric vacuum components and other industrial vacuum operation.
1. Volute pump body , top half and bottom half ,inlet & outlet in bottom half , no disassemble the basic and pipeline systems when maintenance .
2. Improve working life of slurry pump from design aspect.
3. High head pumps with double volutes design, balancing running force on axial direction, make the mechanical seal and bearing longer lifetime.
4. The Impeller with double suctions, whose hydraulic design is verified by CFD and casting is made by precision technologies.
5. Seal with seamless welding technology,replacing structures of the mechanical seal is available, which make maintenance more easy and low the components cost.
6. Bearing has configurations for grease lubrication and thin oil lubrication. Bearings made of stainless steel 304 and has good stability.
7. Structure of bearing body is separated from pump body, which make it available to replace shaft, sleeve and other components without disassemble the pump body.
centrifugal slurry pump
Moreover the pulp pump may also divide the different type specifically from the different angle.
just like LXL-Z series two-phase flow pulp pump and other type as following :
This centrifugal slurry pump is our newest paper pulp making machines, and the pump's conveyor height can reach 25 meters and has small volume, light weight, high quantity of flow, spray far and smart moving features.
Impeller design CAD system development of slurry pump,approach to improve casting quality
of slurry pump improved the working life of paper pulp making machines .
Working Site
Delivery site
Zhengzhou Leizhan Technology Paper Machinery Co.,LTD is a professional manufacturer with more than 30 years manufacturing experience in making complete set of screening, impurity removal, pulping and refining equipment.
Our company is located in Zhengzhou which is the hometown of machinery in Henan Province. We have more than 200 staffs including 50 engineering technicians which can be your best technical support.
With high quality products and perfect pre-sale and after-sale service, we have won lots customers from all over the world.
Factory show
Paper Product Making Machinery
2015 India Exhibition
Pre-sales Service
- Offering comprehensive technical and business consultation services;
- Proposing the most suitable scheme and equipment for our clients;
- Designing and fabricating targeted products according to the special requirements of clients;
- Training periodically high qualified service technician.
After-sales Service
- Highly inspecting equipments in every working procedure, quality comes first;
- Fast & Safe Delivery;
- Assisting our clients for foundation construction of equipments;
- Dispatching engineers to install and debug equipments;
- Training the first-line operators on site;
- Regularly visit clients to solve production problems;
- Providing good life-long maintenance service;
- Providing technical service with a technical service team.
