Flotation waste paper deinking machine for paper recycling
- 20 Set / Sets per Month
- Usaully from Qingdao Port air transportation for inland countries
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
China manufacturer Leizhan paper pulp flotation deinking machine
-
China supply pulp equipment slurry pump
-
2015 popular chain conveyor paper machine / waste paper recycling machine/kraft paper machine manufacturer
-
High Efficient Paper Reject Separator For Paper Pulp/ Pulping Equipment Separator Machine
-
High performance wire mesh machine
-
Applied in paper mills vat former paper machine, vat toilet machine
Product Details
Condition | New | Type | Pulping Equipment | |
Computerized | Yes | Place of Origin | Henan, China | |
Brand Name | Leizhan | Model Number | ZFM | |
Voltage | 380V | Power(W) | 11KW | |
Dimension(L*W*H) | Configuration | Weight | configurations | |
Certification | ISO9001 | Warranty | 12 months | |
After-sales Service Provided | Overseas third-party support available |
international wooden case , to protect equipmrnt safe and sound
Product Description
Flotation waste paper deinking machine for paper recycling
Introduction
In many paper making mills, waste paper is used to make new paper rolls. While waste paper consists of many kinds , some is in white color, some is painted and inked with many colors. When producing white paper, waste paper need to be deinked. This is the main application of this flotation deinking machine .
Application&Feature:
1.Mainly applied to deink recycled pulp, it can effectively remove the ink, light impurities and stickies etc.
2.High efficient flotation, high consistency scum, less fiber loss.
3.Easy maintenance, low power consumption, low operation cost.
4.Only one set can achieve 4-5 stages of flotation, has advantages of less occupied area.
Main Specifications
Type | ZFM 1 | ZFM 2 | ZFM 3 | ZFM 4 | ZFM 5 | ZFM 6 | ZFM 7 | ZFM 8 | ZFM 9 | ZFM 10 | |||
Throughout Capacity(m3/h) | 256 | 400 | 512 | 624 | 800 | 976 | 1152 | 1344 | 1456 | 1600 | |||
Layers | 3-5 | ||||||||||||
Consistency(%) | 1.1±0.1 | ||||||||||||
Production Capacity(t/d) | 55-65 | 85-100 | 110-130 | 130-160 | 170-210 | 210-250 | 240-300 | 290-350 | 310-480 | 340-420 | |||
Consistency of Ink(%) | 2-3 |
Part of deinking process drawing
China manufacturer Leizhan paper pulp flotation deinking machine
1. International package (Wooden case, carbon cast and pallet);
2. Container (as customer requirements)
3. It is suitable for long distance ocean transportation and some small parts can be transported by air
Note: Details follow contract.
1.Pre-sales Service
- Offering comprehensive technical and business consultation services;
- Proposing the most suitable scheme and equipment for our clients;
- Designing and fabricating targeted products according to the special requirements of clients;
- Training periodically high qualified service technician.
2.After-sales Service
- Highly inspecting equipments in every working procedure, quality comes first;
- Fast & Safe Delivery;
- Assisting our clients for foundation construction of equipments;
- Dispatching engineers to install and debug equipments;
- Training the first-line operators on site;
- Regularly visit clients to solve production problems;
- Providing life-long maintenance service;
- Providing technical exchanging;
Zhengzhou Leizhan Technology Paper Machinery Co.,LTD is a professional manufacturer with more than 30 years manufacturing experience in making complete set of screening, impurity removal, pulping and refining equipment. Our company is located in Zhengzhou which is the hometown of machinery in Henan Province. We have more than 200 staffs including 50 engineering technicians which can be your best technical support. With high quality products and perfect pre-sale and after-sale service, we have won lots customers from all over the world.
