Help CenterHigh-Efficiency Fully Automatic Aluminum Foil Lid Punching Machine
Related Products
-
Foil Lid Die Cut MachineUS$ 13,100 - 16,300MOQ: 1 Set -
Aluminum Foil Lid Die Cut MachineUS$ 13,100 - 16,300MOQ: 1 Set
-
High Efficient Lid Punching and Embossing Machine for Yogurt Cup Lids.US$ 16,130 - 20,000MOQ: 1 Set
-
High Quality Fully Automatic Yogurt Aluminum Foil Lid Punching MachineUS$ 16,130 - 20,000MOQ: 1 Set
-
Flexo Yogurt Aluminum Foil Lid Punching MachineUS$ 16,130 - 20,000MOQ: 1 Set
1.Machine Type: Embossing Aluminum foil Punching Machine
2.Application: Die Cutting Aluminum Foil Laminating Film
3.Punching Stroke:80-230strokes/minute
4.Automatic Unwinding Speed: ≤38m/minute
5.Punching Size: 60-500mm
6.Precison: ±0.1mm~±0.25mm
6.Punching Type: Embossing Punching, Profiled Punching
7.Max. Unwinding Diameter: Φ 600mm;Max.Unwinding Width:500mm
8.Die Cut Mould: width:500mm;length:600mm
9.Embossing Roller: 700mm in length
10.Total Power:4.5KW
11.Unity Machine Dimension:(L*W*H):3.0M*1.5M*1.6M
12.Total Weight: 2000KG
13.Color:The whole Body of the machine colored with milky white. Electric Box colored with milky white.
Machine's Equipments and Relevant Parameters
1) Main control: China INOVANC Brand PLC and MCGS brand touch screen.
2) Traction motor: adopt 0.75kw independent motor INOVANCE frequency
converter and PLC link control.
3) Mould driving motor: with 3.7kw independent motor INOVANCE frequency
converter and PLC link control.
4)Tension control motor: 3kw servo motor,INOVANCE PLC Link control.
5) Unwinding device with 50NM magnetic brake tension control.
6) Main motor 3.7kw AC 3 phase frequency conversion motor control by INOVANCE
frequency converter.
7) Unwinding lock: Pneumatic style
8) Leftover material Recycler:Torque rewinding
Skype:w404398276 Aluminum Foil lid Punching Machine
TM:cn1511301465 Aluminum Foil lid Punching Machine
Tel:+86-510-86316851 Aluminum Foil lid Punching Machine
Mobile Phone:+86-15852594903 Aluminum Foil lid Punching Machine
Web: Aluminum Foil lid Punching Machine
Add:NO.50, Huayuan Road, Changjing Town, Jiangyin City,Jiangsu Province, China
Aluminum Foil lid Punching Machine
