Technical Specification:
1.Machine Type: Embossing Aluminum foil Punching Machine
2.Application: Die Cutting Aluminum Foil Laminating Film
3.Punching Stroke:80-230strokes/minute
4.Automatic Unwinding Speed: ≤38m/minute
5.Punching Size: 60-500mm
6.Precison: ±0.1mm~±0.25mm
6.Punching Type: Embossing Punching, Profiled Punching
7.Max. Unwinding Diameter: Φ 600mm;Max.Unwinding Width:500mm
8.Die Cut Mould: width:500mm;length:600mm
9.Embossing Roller: 700mm in length
10.Total Power:4.5KW
11.Unity Machine Dimension:(L*W*H):3.0M*1.5M*1.6M
12.Total Weight: 2000KG
13.Color:The whole Body of the machine colored with milky white. Electric Box colored with milky white.
Machine's Equipments and Relevant Parameters
1) Main control: China INOVANC Brand PLC and MCGS brand touch screen.
2) Traction motor: adopt 0.75kw independent motor INOVANCE frequency
converter and PLC link control.
3) Mould driving motor: with 3.7kw independent motor INOVANCE frequency
converter and PLC link control.
4)Tension control motor: 3kw servo motor,INOVANCE PLC Link control.
5) Unwinding device with 50NM magnetic brake tension control.
6) Main motor 3.7kw AC 3 phase frequency conversion motor control by INOVANCE
frequency converter.
7) Unwinding lock: Pneumatic style
8) Leftover material Recycler:Torque rewinding
Skype:w404398276 Aluminum Foil lid Punching Machine
TM:cn1511301465 Aluminum Foil lid Punching Machine
Tel:+86-510-86316851 Aluminum Foil lid Punching Machine
Mobile Phone:+86-15852594903 Aluminum Foil lid Punching Machine
Web: Aluminum Foil lid Punching Machine
Add:NO.50, Huayuan Road, Changjing Town, Jiangyin City,Jiangsu Province, China yogurt cup lid die cutting aluminum foil lid yogurt cup lid die cutting aluminum foil lid yogurt cup lid die cutting aluminum foil lid yogurt cup lid die cutting aluminum foil lid
