TT7020-12t JOST Type Topless Tower Crane
US$ 100,000 - 120,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Building Construction
Rated Loading Capacity:
12t
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TT7015-10t JOST Type Topless Tower CraneNegotiableMOQ: 1 Unit -
TT6016-8t Good Quality JOST Type Topless Tower CraneNegotiableMOQ: 1 Unit
-
TT5517-8 JOST Type Topless Tower CraneNegotiableMOQ: 1 Set
-
TT5512-8 JOST Type Topless Tower CraneUS$ 60,000 - 65,000MOQ: 1 Unit
-
TT5517-2.9 JOST Type Topless Tower CraneUS$ 30,000 - 33,000MOQ: 1 Unit
Condition
New
Application
Building Construction
Rated Loading Capacity
12t
Rated Lifting Moment
229.5knm
Max. Lifting Load
12T
Max. Lifting Height
186.7m
Span
70m
Place of Origin
Liaoning, China
Brand Name
TOP SKY
Model Number
TT7020-12t
Certification
ISO9001 CE EAC SGS Certificate
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
| TOP SKY Tower Crane Model TT7020-12t | |||||||
| 1.Lifting performance | |||||||
| Max. load | 12t at 15.8m | ||||||
| Tip load | 2.0t at 70m | ||||||
| Max. lifting moment | 229.5knm | ||||||
| 2.Working radius | |||||||
| Jib length | 70m | ||||||
| Max. attachment height | 186.7m | ||||||
| Free standing height(without attachment)fixed type | 51.6m | ||||||
| Drum capacity | 630m | ||||||
| 3.Working speed | |||||||
| Max. hoisting speed | 55LVF | 2 fall | 6t 0-36 m/min | ||||
| 4 fall | 12t 0-15 m/min | ||||||
| 70RCS30 | 2 fall | 6t 0-40 m/min | |||||
| 4 fall | 12t 0-20 m/min | ||||||
| Trolley speed(120JXL1) | 0-63 m/min | ||||||
| Slewing speed(RCV145) | 0-0.7 r/min | ||||||
| Travelling speed(RT443) | 12.5-25 m/min | ||||||
| 4.Steel structure | |||||||
| Standard mast section dimmention | 2.0mX2.0mX3.0m | ||||||
| Select material | Q345B | ||||||
| Corrosion prevention | Sand-blasted before painting | ||||||
| 5.Electric installation(draft) | |||||||
| Hoisting mechanism | 55LVF 55Kw | ||||||
| 70RCS30 51.5Kw | |||||||
| Trolley mechanism | 120JXL1 120Nm | ||||||
| Slewing mechanism | RCV145 145NmX2 | ||||||
| Travelling mechanism(if choose travelling type) | RT443 3.4/1.7KwX4 | ||||||
| Power supply | 380v 50Hz/440v 60Hz | ||||||
| Necessary electric power | 100KVA | ||||||
| Electric equipment | Schneider | ||||||
| 6.Other parts and devices | |||||||
| Cab | With air conditioner and auto-wiper | ||||||
| Telescoping mechanism | Include | ||||||
| Pump and sylinder | Include | ||||||
| Main cable | Include | ||||||
| Foundation bolts | 16 sets | ||||||
| 7.Optional parameter | Draft | Optional items | |||||
| Travelling mechanism | Fixed type | Travelling type or climbing type | |||||
| Jib length | 70m | 45m 50m 55m 60m | |||||
| Steel wire rope length | 630m | >630m please contact us | |||||
| Color | Yellow | As customer's requirement | |||||
Our Certificates of Qualifications
Our Services
Good Quality: Gotten certification of ISO9000:2000 & CE & SGS & EAC.
Best price: Best offer with suitable payment terms.
Good Saled Service: Tow technicists provided to assistant installment,ect.( Buyer beared the fee).
Delivery on Time: Report order progress. Make sure Delivery on time.
Warranty: Provide a warranty of 12 months(Steel wire rope not included)from the bill date(arrival of destination).
