Help CenterTT6016-8t Good Quality JOST Type Topless Tower Crane
Related Products
-
TT5517-8 JOST Type Topless Tower CraneNegotiableMOQ: 1 Set -
TT5512-8 JOST Type Topless Tower CraneUS$ 60,000 - 65,000MOQ: 1 Unit
-
TT5517-2.9 JOST Type Topless Tower CraneUS$ 30,000 - 33,000MOQ: 1 Unit
-
Good Quality Tower Crane TT5512-8 (Russian Standard)NegotiableMOQ: 1 Set
-
TT8422-24t Topless Tower Crane Jost CraneUS$ 100,000 - 200,000MOQ: 1 Unit
Specifications
With ISO9001 GOST CE SGS certificateExport to many countries
Advanced manufacturing technique
High quality
Quick delivery
| TOP SKY Tower Crane Model TT6016-8t | |||||||
| 1.Lifting performance | |||||||
| Max. load | 8t at 14.6m | ||||||
| Tip load | 1.6t at 60m | ||||||
| Max. lifting moment | 182knm | ||||||
| Max. counter weight | 55m 15.8t | ||||||
| 2.Working radius | |||||||
| Jib length | 60m | ||||||
| Max. attachment height | 203.6m | ||||||
| Free standing height(without attachment)fixed type | 57.6m | ||||||
| Drum capacity | 340m/420m | ||||||
| 3.Working speed | |||||||
| Max. hoisting speed | 24PQC20T1 | 2 fall | 4t 0-40 m/min | ||||
| 4 fall | 8t 0-20 m/min | ||||||
| QJ80-I | 2 fall | 4t 40 m/min | |||||
| 4 fall | 8t 20 m/min | ||||||
| Trolley speed(95JXL1) | 0-58 m/min | ||||||
| Slewing speed(RCV95) | 0-0.68 r/min | ||||||
| Travelling speed(RT443) | 11-22 m/min | ||||||
| 4.Steel structure | |||||||
| Standard mast section dimmention | 2.0mX2.0mX3.0m | ||||||
| Select material | Q345B | ||||||
| Corrosion prevention | Sand-blasted before painting | ||||||
| 5.Electric installation(draft) | |||||||
| Hoisting mechanism | 24PQC20T1 24Kw | ||||||
| QJ80-I 30Kw | |||||||
| Trolley mechanism | 95JXL1 95Nm | ||||||
| Slewing mechanism | RCV95 95NmX2 | ||||||
| Travelling mechanism(if choose travelling type) | RT443 3.4/1.7KwX4 | ||||||
| Power supply | 380v 50Hz | ||||||
| Necessary electric power | 60KVA | ||||||
| Electric equipment | Schneider | ||||||
| 6.Other parts and devices | |||||||
| Cab | With air conditioner and auto-wiper | ||||||
| Telescoping mechanism | Include | ||||||
| Pump and sylinder | Include | ||||||
| Main cable | Include | ||||||
| Foundation bolts | 16 sets | ||||||
| 7.Optional parameter | Draft | Optional items | |||||
| Travelling mechanism | Fixed type | travelling or climbing type | |||||
| Jib length | 60m | 30m 35m 40m 45m 50m 55m | |||||
| Steel wire rope length | 360m | >360m please contact us | |||||
| Color | Yellow | As customer's requirement | |||||
HOISTING MECHANISM: 24PQC20T1
The principle of electric control of PC mechanism is simple and mature, with low failure rate, also easy to maintain. This mechanism enjoys six features:
1.Preventing the unexpected shift of direction through electric control
2.High-speed transition inspection. Transit from low-speed to high-speed is only allowed. Can not transit from start zero speed to high speed.
3.When the motor is power on, the brake can be opened only.
4.During the operation process(except emergency stop and limit control ), the brake only works in low-speed running condition
5.When shifting gear, the speed is transmited directly. The strike of the connecting part is very strong, formed by motor output shaft and gear box as well as the gear box and drum. It is quite easy to cause mechnical damage. We have been devoting to improve design and productive technology, so as to enhance the reliability of the transmition system.
6.Due to the limitation of speed regulation of PC mechanism, it can not be used of big tons’ tower crane.
TROLLEY MECHANISM: 95JXL1
Good Quality: Gotten certification of ISO9000:2000 & CE & SGS & GOST.
Best price: Best offer with suitable payment terms.
Good Saled Service: Tow technicists provided to assistant installment,ect.( Buyer beared the fee).
Delivery on Time: Report order progress. Make sure Delivery on time.
Warranty: Provide a warranty of 12 months(Steel wire rope not included)from the bill date(arrival of destination).
