RF Up-Conversion HDMI To ip HD H.264 Encoder built-in Multiplexer, ISDB-T/Tb Modulator

Input

Video Input

Selectable single, dual, four channels HD-SDI

MPEG-4 AVC(H.264) High Profile Level 4.0(HD)

Main Profile Level 3.0(SD)

Resolution:

 1920×1080_60p,1920×1080_50p,

 1920×1080_60i,1920×1080_50i

 1280×720_60p, 1280×720_50p

 720x576_60i,   720x576_50i

 720x480_60i,   720x480_50i

Bit rate:0.8-20Mbps per channel

Audio Input

HDMI embedded audio

Sampling Rates: 48KHz

Bit rate: 64, 128, 192, 256, 384kbps

Audio encoding: MPEG-1 Audio Layer

Quantization:24bit

Multiplexing

1xASI inputs,BNC

Selectable any or all programs of TS inputs

PID passthrough

LCN support (Logical Channel Number)

Output

ASI Output

DVB Interface: Two identical ASI stream out

Comply to EN 50083-9 ASI Standard, BNC, 75Ω

MPEG-TS over IP Output

IP output:100M Base-T Ethernet UDP/IP output, Multicast/Unicast supported

Output Format: 188 bytes

Output Rate: ≤80Mbps

The IP stream will include all the program s and will be sent to the specified multicast or unicast IP address

ISDB-T RF output

Compliant with ARIB STD-B31 standard

Connector F-Type, 75 Ω

1 RF port output

Mixer with 1 RF port input

RF output level:-30~-10dbm(81~97 dbμV), 0.1db step

RF frequency range: 30 to 900 MHz, 1kHz steps

QAM Constellations: DQPSK,QPSK,16QAM,64QAM

Bandwidth: 6Mhz,7Mhz,8 Mhz

Guard Interval:1/4, 1/8, 1/16, 1/32

Transmission mode:2k,4k,8k

Output Return Loss: ≥12dB

Restrain Carrier: ≥58dB

MER: ≥42dB

SNR: ≥50dB

Phase Noise:  @1KHz   ≥90dBc/Hz

@10KHz ≥100dBc/Hz

@100KHz≥105dBc/Hz)

Inputs: MPEG-2 transport stream

Management

100M Base-T Ethernet,RJ45,WEB

7 keys: UP,DOWN LEFT,RIGHT,ENTER,ESC,LOCK

LCD in Front Panel,LED indicate light

Environment

Comply to GB13837-92 & GB8898-88 standard

Power Supply: AC 100-250V 50/60Hz

Power consumption: 20 W

Operating temperature:-10 - 50°C

Storage temperature: -10 - 75°C

Dimensions: 300 (L)x483(W)x44mm(H)  (1RU)

Weight: 5kg

Types

Input interfaces

EMI6510

1xHDMI,1xASI,1xRF in,IP/ASI,RF Out

EMI6520

2xHDMI,1xASI,1xRF in,IP/ASI,RF Out

EMI6540

4xHDMI,1xASI,1xRF in,IP/ASI,RF Out

EMI6515

1xHD-SDI,1xASI,1xRF in,IP/ASI,RF Out

EMI6525

2xHD-SDI,1xASI,1xRF in,IP/ASI,RF Out

EMI6545

4xHD-SDI,1xASI,1xRF in,IP/ASI,RF Out
