HD-SDI To HD H.264 Encoder built-in Multiplexer,
QAM Modulator and RF Up-Conversion
The EMI6205 is a Cost-effective,high definition MPEG4 AVC broadcast distribution encoder with QAM modulation and RF up- conversion built in.It is equipped with up to 4 channels of HD-SDI inputs, 1 ASI input, and output with 2 ASI ports, 1 UDP IP port, and 1 RF port.
The signals source could be from satellite receivers, closed-circuit television cameras, Blue-ray players, and antenna,etc. Its output signal is to be received by a DVB-C standard TV, DVB-C STB.
- Up to 2 HD Encoding module per chassis each module with two channels H.264 encoding
- MPEG-TS Over IP and ASI output built-in multiplexing with 1x ASI input
- Advanced MPEG-4 AVC HP@L4,MPEG-4 AVC MP@L3 video compression
- ASIC technologies which offer broadcast video quality, generally video bitrate advised 720p about 2mbps,1080p about 6mbps for lowest bitrates
- HD-SDI interface, Auto detect the SDI input of resolutions
- Resolution: 1080p,1080i,720p,480i,576i@50/60Hz
- ITU-T,J.83A/B/C encoding type
- RF frequency:30-960MHz,1khz step
- Constellation:16QAM,32QAM,64QAM,128QAM,256QAM(J.83A (DVB-C));64QAM,256QAM(J.83B/C)
- RF attenuation range is from -30~-10dbm (81~97dbμV) with 0.1db step.
- Output data symbol: 3.0~9Mbaud/s(8M BW)
- Bandwidth:6Mhz and 8Mhz
- High performance standard of Encoder/Modulator with superior RF specifications,stream and processing functionality
- PSI/SI generate and NIT insertion,LCN modify
- PID filter,Pass and remapping
- High quality video and audio outputs
- Management via WEB,Local front panel with LCD
- Easy-to-Use System Management
|
Input
|
Video Input |
Selectable single, dual, four channels HD-SDI |
|
MPEG-4 AVC(H.264) High Profile Level 4.0(HD) Main Profile Level 3.0(SD) | ||
|
Resolution: 1920×1080_60p,1920×1080_50p, 1920×1080_60i,1920×1080_50i 1280×720_60p, 1280×720_50p 720x576_60i, 720x576_50i 720x480_60i, 720x480_50i | ||
Bit rate:0.8-20Mbps per channel | ||
Audio Input |
HDMI embedded audio |
|
Sampling Rates: 48KHz | ||
Bit rate: 64, 128, 192, 256, 384kbps | ||
Audio encoding: MPEG-1 Audio Layer | ||
Quantization:24bit | ||
|
Multiplexing
|
1xASI inputs,BNC |
|
Selectable any or all programs of TS inputs | ||
PID passthrough | ||
Output |
ASI Output |
DVB Interface: Two identical ASI stream out |
Comply to EN 50083-9 ASI Standard, BNC, 75Ω | ||
MPEG-TS over IP Output |
IP output:100M Base-T Ethernet UDP/IP output, Multicast/Unicast supported |
|
Output Format: 188 bytes | ||
Output Rate: ≤80Mbps | ||
The IP stream will include all the program s and will be sent to the specified multicast or unicast IP address | ||
|
DVB-C QAM RF output
|
Connector F-Type, 75 Ω |
|
1 RF port output | ||
Mixer with 1 RF port input | ||
RF output level:-30~-10dbm(81~97 dbμV), 0.1db step | ||
RF frequency range: 30 to 960 MHz, 1kHz steps | ||
|
QAM Constellations: 16,32, 64,128,256(J.83A) 64,256(J.83B/C) | ||
Bandwidth: 6Mhz,8 Mhz | ||
|
QAM Encoding:ITU-T J.83 Annex A(DVB),Annex B Annex C(Japan) | ||
Symbol rate range:3~9Mbaud/s | ||
Output Return Loss: ≥12dB | ||
Restrain Carrier: ≥58dB | ||
MER: ≥38dB(64QAM, 6.857MBaud) | ||
SNR: ≥50dB | ||
|
Phase Noise: @1KHz ≥90dBc/Hz @10KHz ≥100dBc/Hz @100KHz≥105dBc/Hz) | ||
SNR: ≥50dB | ||
Accuracy of center frequency:±25KHz | ||
|
Management
|
100M Base-T Ethernet,RJ45,WEB |
|
7 keys: UP,DOWN LEFT,RIGHT,ENTER,ESC,LOCK | ||
LCD in Front Panel,LED indicate light | ||
|
Environment
|
Comply to GB13837-92 & GB8898-88 standard |
|
Power Supply: AC 100-250V 50/60Hz | ||
Power consumption: 20 W | ||
Operating temperature:-10 - 50°C | ||
Storage temperature: -10 - 75°C | ||
Dimensions: 300 (L)x483(W)x44mm(H) (1RU) | ||
Weight: 5kg | ||
1) High quality and low price
2) 3-year warranty
3) Perfect after-sale service and technical support
Types |
In/Output interfaces |
EMI6210 |
1xHDMI,1xASI,1xRF in,IP/ASI,RF Out |
EMI6220 |
2xHDMI,1xASI,1xRF in,IP/ASI,RF Out |
EMI6240 |
4xHDMI,1xASI,1xRF in,IP/ASI,RF Out |
EMI6215 |
1xHDSDI,1xASI,1xRF in,IP/ASI,RF Out |
EMI6225 |
2xHDSDI,1xASI,1xRF in,IP/ASI,RF Out |
EMI6245 |
4xHDSDI,1xASI,1xRF in,IP/ASI,RF Out |
