Dual FTP CAT6 Network Cable
Negotiable
MOQ: 30 Kilometers (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
AOYIPU
Model Number:
FTP5E
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
AOYIPU
Model Number
FTP5E
Number of Conductors
8
Specifications
1.dual FTP CAT6 with BC or CCA conductors; 2. Availabled in PVC and LSZH sheath; 3, have CE, UL and ISO9000-2001 certificate;
- CONSTRUCTION:
-
-
-
-
Conductor:
- Material: soild bare copper
- Number of pairs: 4 pairs
- AWG: 23awg
- Conductor diameter: 0.575±0.003mm
-
Insulation:
- Material: HDPE
- Diameter: 1.18±0.005mm
- Average thickness: 0.2245mm
- Minimum point thickness: 0.222mm
- Divider: PP
- Jacket rip cord: optional
-
Sheath:
- Material: PVC or LSOH
- Nominal diameter: 6.8±0.2mm (13.6mm*6.8mm)
- Average thickness: 0.60mm
- Minimum point thickness: 0.5mm
-
Conductor:
-
-
Operating temperature: -20 to 75°C
Minimum bend radius (install): 8*OD
Flame test: CMX, CM and IEC60332-1
Reference standard: TIA/EIA568B and IEC/ISO11801
