NETWORK WIRE UTP CAT5E 10 PAIRS
Negotiable
MOQ: 50 Kilometers (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
AOYIPU
Model Number:
CAT5E UTP 25PAIRS
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
AOYIPU
Model Number
CAT5E UTP 25PAIRS
Conductor Material
Copper
Insulation Material
PE
Jacket
PVC
Number of Conductors
50
Application
network cable
Specifications
1.NETWORK WIRE with different conductors(Copper/CCA) 2.All cable are pass the UL/CE authenticateConductor:
- Material: solid bare copper
- Number of pairs: 10
- AWG: 24
- Conductor diameter: 0.50±0.003mm
- Insulation:
- Materials: HDPE and FRPE
- Diameter: 0.924±0.005mm
- Average thickness: 0.212mm
- Minimum point thickness: 0.2095mm
- Jacket rid cord: optional
- Sheath:
- Materials: PVC or LSOH
- Nominal diameter: 8±0.2mm
- Average thickness: 0.0mm
- Minimum point thickness: 0.40mm
- Includes:
- BC conductor
- PE insulation
- Rid cord
- PVC sheath
- Operating temperature: -20 to 75°C
- Minimum bend radius (install): (OD) 8mm
- Flame test: CMX, CM, CMR and IEC60332-1
- Reference standard: TIA/EIA568B and IEC/ISO11801
