Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Communication Cable > UTP CAT5E 10 PAIRS CABLE
UTP CAT5E 10 PAIRS CABLE
Negotiable
MOQ: 50 Kilometers (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
AOYIPU
Model Number:
UTP CAT5e
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
25 PAIRS OUTDOOR UTP CAT5E CABLENegotiableMOQ: 15 Kilometers -
CABLE UTP CAT5ENegotiableMOQ: 30 Kilometers
-
Network Wire Waterproof U/UTP Cat5e Cable With PVC Inner and PE Outer JacketNegotiableMOQ: 30 Kilometers
-
Dual FFTP Cat6A CableNegotiableMOQ: 30 Kilometers
-
Dual FTP CAT6 Network CableNegotiableMOQ: 30 Kilometers
Place of Origin
Fujian, China
Brand Name
AOYIPU
Model Number
UTP CAT5e
Specifications
1.NETWORK CABLE UTP CAT5e with different conductors(Copper) 2.All cable are pass the UL/CE authenticateNETWORK CABLE UTP CAT5e
CONSTRUCTION:
-
Conductor:
- Material: solid bare copper
- Number of pairs: 10
- AWG: 24
- Conductor diameter: 0.50±0.003mm
-
Insulation:
- Materials: HDPE
- Diameter: 0.924±0.005mm
- Average thickness: 0.212mm
- Minimum point thickness: 0.2095mm
- Jacket rip cord: optional
-
Sheath:
- Materials: PVC or LSOH
- Nominal diameter: 8±0.2mm
- Average thickness: 0.0mm
- Minimum point thickness: 0.40mm
Operating temperature: -20 to 75°C
Minimum bend radius (install): 8*OD
Flame test: CMX, CM and IEC60332-1
Reference standard: TIA/EIA568B and IEC/ISO11801
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2006
Factory Size
10,000-30,000 square meters
Total Employees
51 - 100 People
