Home > Electrical & Electronics > Passive Components > Capacitor > Quarter Wave Stub EMP Lightning Protector
Quarter Wave Stub EMP Lightning Protector
US$ 6.6 - 14.5
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Four Star
Model Number:
QWN-JK-0-13
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
rf Lightning Protector Wide Brand 1/4 Wave Length Type With 7/16 ConnectorUS$ 6.6 - 14.5MOQ: 100 Pieces -
2 Way Power Splitter 800-2500MHz N Female ConnectorUS$ 3.5 - 5.5MOQ: 50 Pieces
-
N Female Connector 700-2700MHz Power SplitterUS$ 6.5 - 8.5MOQ: 100 Pieces
-
2 Way Power Splitter n Female Connector 700-2700MHzUS$ 5.5 - 8.5MOQ: 50 Pieces
-
N Female Connector 700-2700MHz Power SplitterUS$ 6.5 - 8.5MOQ: 100 Pieces
Place of Origin
Jiangsu, China
Brand Name
Four Star
Model Number
QWN-JK-0-13
Product Description
Quarter Wave Stub EMP Lightning Protector
| Quarter Wave Stub Lightning EMP Protector | ||
| Model No. | QWN-JK-0-13 | |
| Interface | IEC 60169-16/ IEC61643-21 | |
| Electrical | ||
| Characteristic Impedance | 50ohm | |
| Coaxial Connector | N Male to N Female Connector | |
| Frequency Range | 5725-5875MHz | |
| VSWR | ≤1.20@ 5725-5875MHz | |
| Intermodulation 3rd (PIM3) | ≤ -159dBc@43dBm×2 | |
| Insertion Losss | ≤0.15dB | |
| AC Working Vlotage | 2500V / 1 Min No Breakdown and No Arcing Phenomenon | |
| Dielectric Resistance | ≥10000MΩ | |
| Contact Resistance | Center Contact ≤1mΩ | Outer Contact ≤0.25 mΩ |
| Average Power | 600 Watt | |
| Impulse discharge current | 30KA@8/20μS | |
| Residual impulse Voltage(1kV/μs) | <30 | |
| Mechanical | ||
| Durability | Mating cycles ≥500 | |
| Material and Plating | ||
| Parts Name(Components) | Material | Plating (Finish) |
| Body(Housing) | Brass | Tri-Metal(CuZnSn) |
| Insulator | PTFE | — |
| Inner Conductor | Phosphor Bronze | Ag |
| Coupling Nut | Brass | Ni |
| Stub/Cap/Sleeve | Brass | Ni |
| Gasket | Silicone Rubber | — |
| Hardware Kits | Stainless Steel | — |
| Environmental | ||
| Operating Temperature | _45 °C-85 °C | |
| Weatherproof Rate | IP67 | |
| RoHs (2002/95/EC) | Compliant by exemption | |
| EU Directive 2006/95/EC | Compliant | |
