2016 Hot Sale, Wobbler Feeder NWG2324

FOB Price

US$ 60,000 - 70,000 / Set

1 Set(Min. Order)

Port Shanghai Seaport
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Mining Industry
Power Type	Electric	Capacity(t/h)	1000-1300t/h
Place of Origin	Jiangsu, China	Brand Name	Sinoma
Model Number	NWG	Power(W)	37kw
Weight	20t	Certification	ISO9001:2008
Warranty	One Year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Wobbler/Roller Feeder NWG2324

Features:

This machine, specially designed for continuous feeding of the crusher, is the equipment complex with both feeding and screening function. The mud-removal by screening reduces the burden of the crusher, avoids the plugging of the crusher, increases the production efficiency, and reduces the energy consumption.

Structural features:

1. The screening of the required fine materials and clays in the raw materials increases the production capacity of the crushing system, reduces the wear of the crusher, and the work becomes more reliable.
2. For full realizing the working efficiency, the feeding volume can be automatically adjusted according to the load of the crusher.
3. This machine is particularly applicable to screening large lump materials. The mud scraper is under the roller, so this machine is also fit for screening viscous materials.
4. This machine, with a dual function, no addistional space and no additional equipment cost, is suitable for being used during crushing silicon or aluminum ore.

Main Technical Data

Model	Max. Feed Size (mm)	Discharge Size(90%) (mm)	Width (mm)	Length (mm)	Capacity (t/h)
NWG1238	≤600	≤50-75	1236	3650	120-200
NWG1252	≤600	≤50-75	1236	5160	120-200
NWG1538	≤800	≤50-75	1526	3650	200-350
NWG1552	≤800	≤50-75	1526	5160	200-350
NWG1852	≤1000	≤50-75	1826	5160	400-800
NWG2424	≤1500	≤90	2400	2400	1200
