Spa Ozone Generator/Ozone machine for water purification

Specifications

Spa Ozone Generator/Ozone machine for water purification
High Ozone Density With oxygen source
movable

Spa Ozone Generator/Ozone machine  for water purification

**********************************************************

GO-YF Air Cooled Complete Ozone Generator

* Movable

* With built-in oxygen concentrator

* With built-in air cooled ceramic tube

* Teflon connectors for ensuring several years running without ozone leakage



**********************************************************

Applications

Drinking water treatment, Spring water treatment ozone generator, Drinking water bottle disinfection equipment, Pool water treatment ozone generator, Industrial water treatment, Water treatment complete machine, Chemical oxidation, Decolor and bleach ozone machine, Medical water sterilization and disinfection, Food water treatment, Workshop purify, Air conditioner ozone generator, Sterile workshop disinfection equipment, Sterile workshop purifier, Waste gas treatment ozone generator, Waste smoke treatment ozone generator, Environmental control equipment, Indoor air control ozone generator, Pharmaceutical factory air purifier



**********************************************************

Functions:

·Laboratory: chemical oxidation for raw material of flavors and fragrances, small water treatment experiment

·Beverage process industry: such as pure water, spring water and any other water sterilization and disinfection

·Fruits & vegetables process industry: such us keep fresh, storage etc

·Food process industry: water, workshop, sterile room, equipments, tools

·Pharmaceutical industry: water, air conditioner, workshop, dressing room, sterile room etc

·Medical: ward, operating room, medical devices, sterile room etc

**********************************************************

Features:

·With built-in oxygen system, carbon steel sprayed with plastic/SS housing complete ozone generator

·With built-in air cooling ceramic ozone tube, high frequency electric board with stable ozone capacity, long life time

·Compact assembly, it can be movable with wheel

·Adjustable ozone range: 20%--100%, it can working automatic

·Use with over current, over voltage, water protection device, for ensuring ozone machine running safety



**********************************************************

Control panel:

Voltmeter, Ampmeter, Timer, Ozone Ampmeter, Main switch, Power supply switch, Emergency stop, Working LED, Power LED, Alarm

**********************************************************

Specifications

Item	Unit	GO-YF5	GO-YF10	GO-YF15	GO-YF20	GO-YF30	GO-YF40
Oxygen flow rate	LPM	3	3.5	5	8	10	15
Ozone concentration	Mg/L	48.5-52.3	48.5-52.3	49.5-51.2	38.9-41.7	53.2-56.1	43-45.2
Ozone output	G/Hr	5	10-11	14.8-15.4	18.6-20	32-34	40
Power	Kw	≤0.48	≤0.81	≤0.924	≤1.00	≤1.23	≤2.64
Current	A	2.2	3.6	4.2	4.5~4.7	5.6±5%	12
NW	KG	48.3	71	74	77	81.5	136.5
Size	mm	450×500×840	500×660×950				450×930×1180

·Noted: Above ozone capacity were tested under oxygen source

**********************************************************

Packaging

A) Inner layer: plastic bag

B) Middle layer: EPE(Expand aple poly ephylene)

C) Outer Layer: carton/composite wooden cases



**********************************************************

Prompt delivery

1. 3-7 days for portable ozone generator order;

2. 10-30 days for industrial/middle size ozone generator order.

**********************************************************

Payment terms

**********************************************************

About US

WHAT WE DO?



We Provide high-quality ozone generator for:

Ozone generator wholesalers

Retailers and oneline shops (Ebay, Amazon...)

OEM-The custom-made ozone generator are available. Upon customer's idea, drawings, photos etc.

ODM-The modification of the ozone generator after customer's selection is accepted.



Excellent after-sales service:

1 year warranty again the manufacture defect, offer life time consultation on problems occurred.

2M silicone tube and 2PCS air stone gift for any ozone machine order.

Report on the making process.

Marketing feedbacks tracing.

**********************************************************

All of our products are favored and trusted by customers with contemporary design (simplicity, innovation, practicability, multifunction and fashion), convenient operate, durable and its competitive price.



Please don't hesitate to contact with us, you are strongly expecting and welcoming to be the one of our partners in the coming day!



**********************************************************

Factory & Office

**********************************************************

Tips:

1. If use it for air purify, please close door and windows, you just set working time and you can walk away after you coming back will get fresh air.

2. If use it for water purify, please put ozone mchine higher than water for preventing water into machine or you can use with check valve.

3. All kinds of plug are availbale, 110V 220V 380V are available, when you make order pls kindly note us the voltage and plug, thanks a lot!
