Place of Origin Guangdong, China
Brand Name Globalozone
Model Number GO-V

   Wholesale PVDF venturi aeration tube

Venturi



Marks

Model

Quantity

(PC)

Size

(mm)





1

A12057

1

57



2

A25100

1

100



3

A32235

1

235



4

A25152

1

152



5

A48275

1

275



6

A58295

1

295



Venturi is designed to be used with an ozone/oxyen generator for water treatment. It is made of anti-ozone material, PVDF. Connected to your existing filtration system it allows an ozone injection point, where the vacuum effectively sucking the ozone gases into the water flow



Specifications



Model: A12057
Material:PVD
Water flow rate:0.05-0.25 T/Hr
Specification:

  1. Inlet & Outlet diameter 1/5’ external screw thread
  2. Valve bonnet of Gas Inlet is 1/8’;
  3. flexible hose
  4. Length: 57 mm

Model: A25100
Material:PVDF
Water flow rate: 0.1-1 T/Hr
Specification:

  1. Inlet & Outlet diameter 1/2’ external screw thread
  2. Valve bonnet of Gas Inlet is 1/4’;
  3. flexible hose is 1/4
  4. Length: 100 mm

Model : A32235
Material: PVDF
Water flow rate:3-10 T/Hr
Specification:

  1. Inlet & Outlet diameter 1’ external screw thread.
  2. Valve bonnet of Gas Inlet is 1/2’;
  3. flexible hose is 1/8
  4. Length: 230 mm






Model: A25152
Material: PVDF
Water flow rate: 1~3 T/Hr
Specification:

  1. Inlet & Outlet diameter3/4’ external screw thread
  2. Valve bonnet of Gas Inlet is 1/4’;
  3. flexible hose is 1/4’
  4. Length: 152 mm

Model: A48275
Material: PVDF
Water flow rate:10~25 T/Hr
Specification:

  1. Inlet & Outlet diameter 1.5’ screw thread
  2. Valve bonnet of Gas Inlet is 1/2’;
  3. flexible hose is 1/2’
  4. Length: 275mm

Model: A58295
Material: PVDF
Water flow rate: 25~50T/Hr
Specification:

  1. Inlet & Outlet diameter 2’ screw thread
  2. Valve bonnet of Gas Inlet is 1.25’;
  3. flexible hose is 1/2
  4. Length: 295mm








**********************************************************************

Wholesale PVDF venturi aeration tube

 Venturi Aeration Tube System Diagram For Water Treatment

Wholesale PVDF venturi aeration tube

Wholesale PVDF venturi aeration tube



**********************************************************************

Prompt delivery

1. 3-7 days for venturi aeration tube order;

2. 10-30 days for venturi aeration tube order;

3. Shipping could be courier, airline or sea.

**********************************************************************



Payment terms



**********************************************************************



About US

WHAT WE DO?



We Provide high-quality venturi aeration tube for:

Venturi aeration tube to wholesalers

Retailers and oneline shops (Ebay, Amazon...)

OEM-The custom-made venturi aeration tube is available. Upon customer's idea, drawings, photos etc.

ODM-The modification of the venturi aeration tube after customer's selection is accepted.



Excellent after-sales service:

1 year warranty again the manufacture defect, offer life time consultation on problems occurred.

2M silicone tube and 2PCS air stone gift for any ozone machine order.

Report on the making process.

Marketing feedbacks tracing.

**********************************************************************



All of our products are favored and trusted by customers with contemporary design (simplicity, innovation, practicability, multifunction and fashion), convenient operate, durable and its competitive price.



Please don't hesitate to contact with us, you are strongly expecting and welcoming to be the one of our partners in the coming day!

**********************************************************************

Factory & Office



**********************************************************************

Tips:

If you will use it for water treatment, please use with check valve together for preventing water into ozone/oxygen machine.
