Fish Farm Protein Skimmer for RAS Recirculating Aquaculture System

 Fish farm protein skimmer for RAS recirculating aquaculture system

Water Treatment Capacity:10-200T/Hr

We use with special structure, no energy consumption, high efficiency for our protein skimmer.

It used to reduce the physical and chemical gels.

It used the role of adsorption of surface tension of the bubble to enrichment and separation organic, removal the colloidal suspension, cellulose, protein, bait and faeces and other organics in the wastewater.

Meanwhile, the protein separator can be used as an ozone mixing tower, which can separate protein and use ozone to do the disinfections.

Component parts

Water input, PDO air intake device, mixing chamber, collecting pipe, sewage disposal, ozone adding device, water output etc.

 Working system

 First, water enter from the bottom of Protein Skimmer, “S” shape water stream, water moving up and then roll down to the water outlet;

Second, using the PDO device for producing bubble, and it enters into the mixing chamber with water together, liquid and air fully mixing in waterwhen the water is rolling then reaches to the water outlet, water goes out from the bottom, but the not dissolved & suspended particles are gather in the surface of micro-bubble, then enter into the collecting pipe, coming out from the sewage disposal;

 Third, treated water coming out from the main water outlet, water outlet valve can adjust the liquid level of Protein skimmer.

 Features

1. Instead the using of Venturi, Booster pump, low power for saving energy.

2. Using the collecting pipe, no need to clean, for saving water.

3. PDO air intake device produces abundance air bubble, for high separate efficiency.

4. Using two ways water stream design, for high air-liquid mixing result, high separate efficiency.

5. Trouble-free design, long service life but free maintenance.

 Functions

 1. Removing organism such as night soil, colloid etc, for reducing the load of biological treatment and ensuring the water quality.

 2. Increasing the dissolved oxygen in water, for improving the biological treatment efficiency.

 3. Removing the harmful air in water, stabilize the PH in water.

 4. Mixing ozone in water also has the function of sterilization, disinfect ion and remove algae in water.

 Application

1. Seafood cultivating factory

2. Seawater hatcheries

3. Oceanopolis, aquarium etc

4. Swimming pool water treatment

5. Sewage water treatment, and the lines used for ozone mixing in water

 Specifications:

Remarks: Above specifications are valid for 15 days.

Packaging

A) Inner layer: plastic bag

B) Middle layer: EPE(Expand aple poly ephylene)

C) Outer Layer: carton/composite wooden cases

Promptly delivery

1. 3-7 days for portable ozone generator order;

2. 10-30 days for industrial/middle size ozone generator order;

3. Shipping could be courier, airline or sea.

Excellent after-sales service:

1 year warranty again the manufacture defect, offer life time consultation on problems occurred.

2M silicone tube and 2PCS air stone gift for any ozone machine order.

Report on the making process.

Marketing feedbacks tracing.

Payment terms

About US

WHAT WE DO?

We Provide high-quality aquaculture water treatmet system for:

Aquaculture equipment wholesalers/end users

Retailers and oneline shops (Ebay, Amazon...)

OEM-The custom-made aquaculture equipment are available. Upon customer's idea, drawings, photos etc.

ODM-The modification of the aquaculture equipment after customer's selection is accepted.

All of our products are favored and trusted by customers with contemporary design (simplicity, innovation, practicability, multifunction and fashion), convenient operate, durable and its competitive price.

Please don't hesitate to contact with us, you are strongly expecting and welcoming to be the one of our partners in the coming day!
