Vacuum Nitriding Furnace
Brief
This vacuum nitriding furnace is mainly used for heat treated parts of nitriding under low vacuum conditions, with the function of changing pressure and ventilating automatically, to ensure the protective atmosphere in every corner of furnace hearth fresh and active.
Advantages
1.Fast infiltration speed, high surface hardness, good atmosphere uniformity and sealing condition.
2.Heating chamber and cooling chamber are separated, high production efficiency, low using cost.
3.Good cooling uniformity, small distortion of the heat treated parts.
4.The nozzles of nitriding gas are arranged evenly on the heating chamber, with good nitriding layer thickness uniformity.
5.The waste gas is pumped into sealed water box by the vacuum pump then will be cleared out after processed specially, It is an energy - saving eco-friendly product.
Technical parameters
Effective dimensions (mm) |
Loading capacity(Kg) |
Power (kw) |
Max. Temp |
Furnace temperature uniformity |
Final vacuum (Pa) |
600*400*400 |
100/150 |
60 |
1300℃ |
±5℃ |
4.0×10-¹ 6.7×10-³ |
750*500*500 |
250/300 |
80 |
|||
900*600*600 |
400/500 |
120 |
|||
1200*800*800 |
8000/1000 |
220 |
|||
1500*1500*800 |
3500/4000 |
300 |
