solar street light charge controller solar power street light 12v 24v 48v solar charge controller

Type

CIS 05

CIS-2L 05

CIS 10

CIS-2L 10

CIS 20

CIS-2L 20

System voltage

12/24 V auto recognition

Max. charge/load  current

5 A

10 A

20 A

Floatcharge

13.8/27.6 V (25 °C)

Main charge

14.4/28.8 V (25 °C), 30 min. (daily)

Boostcharge

14.4/28.8 V (25 °C), 2 h

Activation:battery voltage < 12.3/24.6 V

Equalization

14.8/29.6 V (25 °C), 2 h

Activation:battery voltage < 12.1/24.2 V (at least every 30 days)

Deep discharge protection: Cut-off voltage

Reconnectlevel

11 – 12 V / 22 – 24 V

12.8/25.6 V

Overvoltage protection

15.5/31.0 V

Undervoltage protection

10.5/21 V

Max. panel voltage

(Overvoltageprotection  by varistor)

55 V

Temperaturecompensation

(Charge voltage)

−25 mV/K at 12 V

−50 mV/K at 24 V

Max. own consumption

5 – 8 mA at 12 V

6 – 10 mA at 24 V

Grounding

Positive grounding  possible

Ambienttemperature

−40 to +60 °C

Max. altitude

4,000 m above sea level

Batterytype

Leadacid (GEL, AGM, flooded)

Adjustmentrange: Evening/morninghours Night/day detection

0 – 15 h / 0 – 14 h

2.5 – 10 V

Wire length

10 cm

Dimensions (W x H x D)

82 x 58 x 20 mm

Weight

150 g

Wire cross section

1.5 mm2

1.5 mm2

2.5 mm2

Type of protection

IP68 (1.5 m, 72 h)
