Specifications
Sensor: 1/3" SONY CCD,CMOS sensor is optionalResolution: WDR700/700 /600/420TVL,
IR Leds: 42pcs of 5mm IR LEDs,
KD-IW8847MF
IR Water-proof Camera, 42pcs IR leds, 30-40M IR range, 4 /6 / 8 mm fixed lens
Product Features:
- Ø Sensor: 1/3” SONY CCD,CMOS sensor is optional
- Ø Resolution: WDR700/700 /600/420TVL,
- Ø IR Leds: 42pcs of 5mm IR LEDs,
- Ø IR Range: 30-40M IR Range,
- Ø Lens: 4 /6 /8 mm fixed lens,
- Ø OSD menu, 3D DNR, Smart IR
- Ø IP range: IP66, high reliability
- Ø Material: Aluminum alloy casing
Application Places:
Apply to the financial, supermarket, telecommunications, government, schools, airports, factories, hotels, museums and other places of requirement of high-definition.
| CMOS: | 1/3"PC3089 CMOS Sensor, With IR-Cut | 700TVL |
| CMOS: | 1/4"139 CMOS + FH8510 DSP,with IR-Cut | 800TVL |
| CMOS: | 1/3"SONY 138COMS + 8520 DSP, Low Lux | 1300TVL |
| CCD: | 1/3"SONY 633 CCD + SONY 3142 DSP | 420TVL |
| CCD: | 1/3"SONY 639 CCD + Nextchip 2090 DSP | 600TVL |
| CCD: | 1/3"SONY 811 CCD + SONY Effio-E DSP | 700TVL |
| CCD: | 1/3"SONY 663 CCD + SONY Effio-V DSP,WDR | 700TVL,WDR |
| AHD: | 1/4"OV9712 CMOS + NVP2431H DSP | 1.0Megapixel |
| AHD: | 1/3"SONY238 CMOS + NVP2431H DSP, Low Lux | 1.3Megapixel |
| TVI: | 1/4"AR0141 CMOS + 8060 DSP, Low Lux | 1.0Megapixel |
| TVI: | 1/3"AR0130 CMOS + 8521 DSP, Low Lux | 1.3Megapixel |
Model |
KD-IW8847MF |
|||
Type |
IR Weather-proof Camera |
|||
Horizontal Resolution |
WDR 700TVL |
700TVL |
600TVL |
420TVL |
Effective Pixels (HxV) |
PAL:976×582 NTSC: 976x494 |
PAL:976×582 NTSC: 976x494 |
PAL:752×582 NTSC:768×494 |
PAL:500×582 NTSC:510×492 |
Signal System |
PAL / NTSC |
|||
Image Sensor |
1/3"SONY 662/663 CCD |
1/3"Sony 810/811 CCD |
1/3"Sony 638/639 CCD |
1/3"Sony 632/633 CCD |
Digital Signal Processor |
SONY Effio-P DSP |
SONY Effio-E DSP |
Nextchip 2090 DSP |
Sony 3142 DSP |
Mini Illumination |
0.02lux(IR on) 0.00lux(IR off) |
0.02lux(IR on) 0.00lux(IR off) |
0.05lux(IR on) 0.00lux(IR off) |
0.01lux(IR on) 0.00lux(IR off) |
Lens |
4 /6 /8 mm fixed lens |
|||
IR LEDs |
5X42PCS |
|||
Night Vision |
30-40M |
|||
OSD |
OSD |
OSD |
OSD |
- |
WDR |
WDR |
D-WDR |
D-WDR |
- |
DNR |
3D-DNR |
3D-DNR |
2D-DNR |
- |
AES |
PAL=1/50 ~1/100,000sec;NTSC=1/60 ~1/100,000sec |
|||
S/N Ratio |
> 48dB(Auto Gain Off) |
|||
BLC |
On/Off |
On/Off |
On |
On |
AGC |
Auto/Manual/Off |
Auto/Manual/Off |
Auto |
Auto |
White Balance |
ATW/Manual/Auto |
ATW/Manual/Auto |
ATW |
ATW |
Video Output |
1.0V P-P,75Ω |
|||
Operating Temperature |
-10 ~ 50℃(relative humidity: max95%) |
|||
Power Voltage |
DC12V±10% |
|||
Suggest Power Adaptor |
DC12V/1A |
|||
IP Range |
IP66 |
|||
Material |
Aluminum alloy |
|||
Dimension |
270(L) x150(W) x97(H)mm |
|||
Weight |
1.00 KG |
|||
Guarantee |
2 years |
|||
