2239E-OT 22" Wide LCD Open-frame Touchmonitor
22 inch open frame lcd with infrared/ SAW touch screen
Features
- Long lasting product cycle-enclosure
- 1000:1 contrast ratio, and 250-nit brightness (LCD panel)
- High quality panel with 160° x 160° or 160° x 160°(option) viewing angle
- Optional front mount and rack mount bezels
- Future generation panels phased-in without external changes
- Mounting options including rear-mount and VESA mount
- Multilingual on-screen display (OSD)
- Fully RoHS compliant
Specifications
Case/Bezel Color |
Steel/black |
|
Display Size |
21.5" Wide |
|
LCD Type |
TFT LCD |
|
Aspect ratio |
16:9 |
|
Useful Screen Area |
476.64mm x 268.11mm mm |
|
Touch panel |
Intellitouch screen |
|
Touch interface |
Dual Serial / USB |
|
Touch response time |
10ms (typical) |
|
Touch Monitor Dimensions |
526.0 x 345.0 x 54mm |
|
Optimal (native) Resolution |
1920 x 1080 |
|
LCD panel Pixel pitch |
0.248x 0.248 mm
|
|
Plug and Play |
VESA DDC 1/2B |
|
LCD panel Colors |
16.7 million |
|
LCD panel Brightness |
250 cd/m2 |
|
LCD panel Response Time |
5 ms |
|
|
Viewing Angle (typical, from center) |
Horizontal (left/right)
|
±85° or 170° total |
Vertical (up/down) |
±80° or 160° total |
|
Contrast Ratio |
1000:1 |
|
Input Video signal connector |
RGB Analog Video and DVI Video (optional) |
|
Input sync format |
31.5-80.0 kHz 60-75 Hz |
|
Power Supply Type |
External AC to DC power brick |
|
Monitor input: +12VDC ±5%,4.0 A; DC Jack (2.5) | ||
AC to DC power brick input: 100-240 VAC, 50/60 Hz | ||
|
Power dissipation: 30W max
| ||
On-screen display(OSD) |
Controls(back):PowerMenuUpDownAuto; Settings: contrast , brightness, H/V position; RGB(color temp), clock ,phase , recall; Languages: English, German, French ,Spanish, Japanese; |
|
Temperature |
Operating: 0°C to 40°C; Storage -20°C to 60°C |
|
Humidity (non condensing) |
Operating: 20%-80%; Storage: 10%-90% |
|
Shipping Carton Dimensions |
556x456x206mm |
|
Weight (approx.) |
Actual:8 kg; Shipping: 10kg |
|
Warranty Monitor |
3 years(Except for LCD panel 1 year) |
|
Backlight lamp life: typical 50,000 hours to half brightness | ||
Agency Approvals |
CE/FCC/Rohs |
|
Mounting Options |
75 mm or 100 mm VESA mount |
|
