1931E-OT 19" LCD Touch screen monitor
19" LCD open frame touch monitor(ELO 3M compatible) for gaming POG WMS videos slot machines
Features
- Long lasting product cycle-enclosure
- 1000:1 contrast ratio, and 250-nit brightness (LCD panel)
- High quality panel with 160° x 160° or 178° x 178°(option) viewing angle
- Optional front mount and rack mount bezels
- Future generation panels phased-in without external changes
- Mounting options including rear-mount and VESA mount
- Multilingual on-screen display (OSD)
- Fully RoHS compliant
Specifications
Case/Bezel Color |
Steel/black |
||
Display Size |
19.0" |
||
LCD Type |
TFT LCD |
||
Aspect ratio |
4:3 |
||
Useful Screen Area |
376 mm x 301mm |
||
Touch panel |
SAW/Resistive Touch Screen |
||
Touch interface |
USB or Serial |
||
Touch response time |
10ms/5ms (typical) |
||
Touch Monitor Dimensions |
415.0 x 343.0 x 51mm |
||
Optimal (native) Resolution |
1280 x 1024 |
||
LCD panel Pixel pitch |
0.294x 0.294 mm
|
||
Plug and Play |
VESA DDC 1/2B |
||
LCD panel |
LCD parameter |
High LCD parameter (option) |
|
LCD panel Colors |
16.7 million |
16.7 million |
|
LCD panel Brightness |
250 cd/m2 |
250 cd/m2 |
|
LCD panel Response Time |
8 ms |
25 ms |
|
|
Viewing Angle (typical, from center) |
Horizontal (left/right)
|
±80° or 160° total |
±89° or 178° total |
Vertical (up/down) |
±80° or 160° total |
±89° or 178° total |
|
Contrast Ratio |
1000:1 |
1000:1 |
|
Input Video signal connector |
Mini D-Sub 15-Pin VGA type and DVI type (optional) |
||
Input sync format |
31.5-80.0 kHz 60-75 Hz |
||
Power Supply Type |
External AC to DC power brick |
||
Monitor input: +12VDC ±5%,4.0 A; DC Jack (2.5) | |||
AC to DC power brick input: 100-240 VAC, 50/60 Hz | |||
|
Power dissipation: 48W max
| |||
On-screen display(OSD) |
Controls(back):Power,Menu,Up,Down,Auto; Settings: contrast, brightness, H/V position; RGB(color temp),clock, phase, recall; Languages: English, German, French ,Spanish, Japanese; |
||
Temperature |
Operating: 0°C to 40°C; Storage -20°C to 60°C |
||
Humidity (non condensing) |
Operating: 20%-80%; Storage: 10%-90% |
||
Shipping Carton Dimensions |
556 x 456 x206 mm |
||
Weight (approx.) |
Actual: 6.5 kg; Shipping: 9 kg |
||
Warranty Monitor |
3 years(Except for LCD panel 1 year) |
||
Backlight lamp life: typical 50,000 hours to half brightness | |||
Agency Approvals |
CE/FCC Rohs |
||
Mounting Options |
75 mm or 100 mm VESA mount |
||
