Help CenterGold Mining Equipment Spiral Concentrator Spiral Chute Spiral Separator With ISO and CE Qualifications
Related Products
-
FLG Series Spiral Classifier Machine for MiningUS$ 1,000 - 999,999MOQ: 1 Set -
Factory Price High Frequency Screen Machine for SaleUS$ 1,000 - 999,999MOQ: 1 Set
-
China Best Selling Types Sand Screening Machine With MuitifuctionUS$ 1,000 - 999,999MOQ: 1 Set
-
Stone Production Line Machinery Mining Vibrating ScreenUS$ 1,000 - 999,999MOQ: 1 Set
-
Gold Separating Machine Concentrating Shaking Table With High Efficiency for SaleUS$ 1,000 - 999,999MOQ: 1 Set
Specifications
fiberglass spiral chute:1.Model:5LL series;
2.Capacity:0.2-40t/h;
3.Height:1.5-6.6m;
4.Application:iron, stannum, tungsten.
Features of spiral concentrator spiral chute spiral separator :
1.Simple structurer;
2.Light weight, lower power consumption;
3.Easy operation, reliable operation, easy maintenance;
4.Smaller area, high capacity, and high separating efficiency.
Structure of spiral concentrator spiral chute spiral separator :
Spiral chute is mde of feeder, feed chute, spiral flute, bracket, intercepting slot, and supporting frame,etc.
Application of spiral concentrator spiral chute spiral separator :
Spiral is used to process iron, stannum, tungsten, tantalum. niobium, gold ore, colliery, monazite, rutile and zircon of the size btween 0.3 and 0.02mm, metals and nonmetal minerals with enough proportion deviation.
Technical Parameters of spiral concentrator spiral chute spiral separator :
| Model | Helix No. | Cycle | Feed Size(mm) | Feed Density(%) | Capacity(t/h) | Area(m2) | Height (m) |
| 5LL400 | 1-2 | 4-5 | 0.02-2 | 30-50 | 0.5-0.2 | 0.25 | 1.5 |
| 5LL600 | 1-2 | 4-5 | 0.02-2 | 30-50 | 0.8-1.2 | 0.5 | 2.6 |
| 5LL900 | 2-3 | 4-5 | 0.03-3 | 30-50 | 2-3 | 1.2 | 3.2 |
| 5LL1200 | 2-4 | 4-5 | 0.03-3 | 30-50 | 4-6 | 2 | 5.23 |
| 5LL2000 | 2-4 | 3-5 | 0.04-4 | 20-45 | 15-40 | 5.7 | 6.6 |
Any change of technical parameters, there is no further notice.
