Help CenterHot Sale Vibrating Feeder With Large Capacity
Related Products
-
Stone Breaking Machine Impact Crusher With Resonable Price For SaleUS$ 1,000 - 99,999MOQ: 1 Set -
Spiral Sand Washing Machine, Sand Cleaning Machinery ShanghaiUS$ 1,500 - 9,999MOQ: 1 Set
-
PF1214 Impact Crusher Manufacturer&ExporterUS$ 1,000 - 99,999MOQ: 1 Set
-
PF Series 1214-III Impact Crusher MachineryUS$ 1,000 - 99,999MOQ: 1 Set
-
Energy-saving Fine Sand Vibrating ScreenUS$ 1,000 - 999,999MOQ: 1 Set
Specifications
Vibrating feeder :1.Stable vibration;
2.Reliable operation;
3.Low energy consumption;
4.ISO9001:2000, low noise.
Application of Vibrating feeder :
Vibrating Feeder China is mainly used to feed materials evenly and continuously into belt conveyor, bucket elevator, screening and crushing equipment before primary crusher, also used for screening fine materials to increase the processing capacity of crusher. The feeding amount can be adjusted flexibly to achieve centralized control and automatic control in the production process.
1. Stable vibration, reliable operation, low energy consumption and low noise.
2. The fence distance can be adjusted, special design of fence can prevent material blocking.
3. Adjustable speed motor applies matched motor to control feeding capacity easily and avoid frequent motor re-start.
Types of Vibrating feeder :
We have various of China Vibrating Feeder, such as GZD-900×3800,GZD-950×3800,GZD-1100×4900,GZD-1200×4900,GZD-1300×6000 etc. In order to give you a responsible quotation, you can inform us the following information:
- What's the material you are going to deal with?
- What's the granularity of the material?
- What's the granularity of the final products are you going to achive?
- What's the producing capacity you are going to achieve?
Our engineers will suggest you the most suitable one for you according to your information.
Vibrating feeder parameter:
| Model | Funnel size (mm) | Max. feed size (mm) | Capacity(t/h) | Power (kw) | Weight (t) | Overall dimension (L x W x H) ( mm) |
| GZD-900×3800 | 900×3800 | 400 | 80-120 | 6 | 3.89 | 3900x1500x1200 |
| GZD-950×3800 | 950×3800 | 500 | 120-210 | 6 | 3.98 | 3900×1600×1250 |
| GZD-1100×4900 | 1100×4900 | 580 | 160-320 | 11 | 4.52 | 5000×1800×1500 |
| GZD-1200×4900 | 1200×4900 | 650 | 200-430 | 15 | 5.2 | 5000×1900×1700 |
| GZD-1300×6000 | 1300×6000 | 900 | 450-600 | 15 | 6.5 | 6150×1900×2100 |
Any change of technical parameters, there is no further notice.
After-Sale Service:
Erection and Commissioning
Operator Training
Spare Parts Supply
Warranty Terms: More than 12 months
Delivery Time:25~30 days after receiving advanced payment
Products Certificate: TUVRheinland CE, ISO9001:2000
We(Shanghai LIPU Heavy Industry Co.,Ltd) believe that you can rely on us as we provide you quite satisfactory service and products with best quality at most competitive price in the world. We are very happy if you do not hesitate to send us any of your inquiries and we will always give satisfactory services.
Looking forward to hearing from you at your convenience!
