Best Effective Ball Mills/ball Mill Machine/ball Grinding Machine photo-2
Best Effective Ball Mills/ball Mill Machine/ball Grinding Machine photo-3
Best Effective Ball Mills/ball Mill Machine/ball Grinding Machine photo-4
US$ 1,500 - 999,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Ball Mill, Horizontal Ball Mill Price for Sale
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Shanghai Lipu Heavy Industry Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai qingdao dalian for Horizontal Ball Mill Price for Sale export
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Ball Mill, Horizontal Ball Mill Price for Sale
Motor Type AC Motor
Power(W) 15000-2250000
Capacity(t/h) 0.9-353
Place of Origin Shanghai, China
Brand Name LIPU
Model Number various
Dimension(L*W*H) According to different capacities
Weight 4.2-300
Certification CE,BV,ISO9001-2008, CE,ISO9001:2000,CV
Warranty one year, One year
After-sales Service Provided Engineers available to service machinery overseas

Best effective ball mills/ball mill machine/ball grinding machine

Brief Introduction of ball grinding machine:

LIPU ball mill is mainly used to grind materials in mineral, cement, refractory, chemical industry, etc.  When ball mill works, certain water and other liquid will be added into materials to increase flowability of materials, so the capacity is increased.

Features of ball grinding machine:

1. Large application range, simple structure and convenient maintenance.

2. Large capacity and continuous work are very obvious.

3. Barrel lining and grinding media can apply various abrasive materials.

4. Installation and adjustment are very convenient and easy to be operated.

Best effective ball mills/ball mill machine/ball grinding machine

Working Principle of ball grinding machine:

When the Ball Mill works, motor and speed reducer transmit torque force to big and small gears of Ball Mill, so the barrel rotates. When the barrel rotates, Steel balls or other grinding media in the barrel are lifted to a certain height and fall down freely, so materials in the barrel are impacted. Grinding media mixing with materials impact and grind materials continuously. The grinding media and materials impact and grind each other when the Ball Mill rotates continuously. The final product will be discharged from outlet when it meets the request, so the grinding process is finished.

Best effective ball mills/ball mill machine/ball grinding machine

Technical Parameters of ball grinding machine:

Model

Effective volume(m3)

Max. steel ball load (t)

Capacity (t/h)

Power(kW)

 Rotary speed(rpm)

Weight (t)


MQG

MQY

MQS

MQG

MQY

MQS



φ900×1800

1

1.3

1.7

2

0.9-1.6

1.7-3.2

2-3.7

15

37

4.2

φ900×2100

1.1

1.5

1.9

2.3

1-1.9

2-3.7

2.3-4.3

18.5

37

4.9

φ900×3000

1.6

2.2

2.8

3.3

1.4-2.7

2.9-5.4

3.3-6.2

30

37

7.6

φ1200×2400

2.4

3.3

4.1

4.9

2.2-4

4.3-8

5-9.2

30

35

8.7

φ1200×3000

3

4.1

5.2

6.2

2.7-5

5.4-10

6.2-12

37

35

13

φ1200×4500

4.4

6.2

7.7

9.3

4-7.5

8.1-15

9.3-17

55

35

14

φ1500×3000

4.8

6.6

8.3

10

4.3-8

8.6-16

10--19

75

29

15

φ1500×4500

7.1

10

12

15

6.5-12

13-24

15-28

110

29

16

φ1500×5700

9

13

16

19

8.2-15

16-31

19-35

130

29

24

φ1830×3000

7.1

10

12

15

6.4-12

13-24

15-28

130

24.5

28

φ1830×4500

10.6

15

18

22

10--18

19-36

22-41

155

24.5

32

φ1830×6500

15.3

21

27

32

14-26

28-52

32-60

210

24

35

φ1830×7000

16.5

23

29

34

15-28

30-56

35-64

245

24

37

φ2100×3000

9.4

13

16

20

9--16

17-32

20-37

155

23.5

42

Producing Process of ball grinding machine:

Best effective ball mills/ball mill machine/ball grinding machine

  Delivery Site of ball grinding machine:

Best effective ball mills/ball mill machine/ball grinding machine

 Work Site of ball grinding machine:

Best effective ball mills/ball mill machine/ball grinding machine

Best effective ball mills/ball mill machine/ball grinding machine

Best effective ball mills/ball mill machine/ball grinding machine

Best effective ball mills/ball mill machine/ball grinding machine

Best effective ball mills/ball mill machine/ball grinding machine

Best effective ball mills/ball mill machine/ball grinding machine
