Intelligence Weigher indicator for belt conveyor weighing feeder
- 10000 Piece / Pieces per Month
- shanghai
- T/T Credit Card PayPal
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | SILVANUS | Model Number: | SW-2000 |
| Type: | Other, weighing indicator | Power Supply: | AC 220V | Display Type: | LCD |
Product Description
SW –2000 Wireless weighing indicator
Product Introduction
SW - 2000 type on-site installation type controller and panel installation type controller ,both using microprocessor, dealing with the weighing sensor signal belt speed signal, calculation flow of material and the accumulative amount, showing result value on the indicator. It is Widely usd for the electric power, coal, metallurgy, mine, port, chemical industry, building materials industries.
Product Feature
- Suitable for constant feeder, batching belt scale, electronic measuring belt, belt speed detection device, etc
- Using DCS can realize the remote control operation
- 2 screen type LCD and VFD , divided into embedded and wall-mounted specifications in order to adapt different environment
- Automatic correction of zero, the weight of belt and belt speed, the cumulative amount.
- Using full digital input set mode and parameters, system with functions of physical objects and simulation calibration
- A fault tips, the weight of fault signal selection and outage alarm function
- Characteristics of signal acquisition, error correction, state judgment, run shows, PID control, DCS communication and other functions
- Data storage used the FLASH mode, when the system is powered off automatically save all kinds of process data, after power on again, keep in the original process parameters on the run
- Instrument used a highly reliable device, at the same time, combined with advanced anti-interference technology, the electrostatic, spark, electromagnetic interference, etc have very high resistance ability
The Screen display
Technical Parameters |
| |||
| Item No. | SW-2000 | ||
| Voltage range | AC 220V (AC175-285V),50Hz/60Hz | ||
| Power | 30W | ||
| Working temperature | -10-50℃ | ||
| Humidity range | ≤95%RH | ||
| Dimension | Wall-mounted:315(W)x 148(D)x 380(H)mm | ||
| Embedded:280(W)x 340(D)x 160(H)mm | |||
| Product Weight | 4.0 kg | ||
| Linearity | 0.01FS | ||
| Accuracy | 0.10% | ||
| Cumulant Scope | 0-99999900 t | ||
| Instantaneous flow range | 0.0020-99999.9 t/h | ||
| Measure Unit | 0.001kg,0.01kg,0.1kg,1kg,0.01t,0.1t,1t… | ||
| Speed Sensor Voltage | DC 24V,50mA | ||
| Speed input range | 0-3000Hz, 0-24V | ||
| Suitable for belt width | 500-1600mm | ||
| Transducer sensitivity | 2.0-3.0 mV/V | ||
| Sensor excited voltage | DC 9V, 200mA,parallel 1-4 pcs Load sensor | ||
| Speed sensor type | photoelectric/Electromagnetic/Hall Sensor/proximity switch | ||
| Load cell type | Strain gauge load cell | ||
| Display | 240*128 LCD display | ||
| Analog input | 4-20mA,The remote setting traffic signal,DCS interface | ||
| Analog output | 4-20mA, 2 outlets,flow signal output,control signal output | ||
| DCS interface | flow signal corresponding to the instantaneous flow rate | ||
| control signal :Used to control the regulator output | |||
| MODBUS interface | RS 232: length 1.5m | ||
| (RS232/RS485) | RS 485:length 1000m | ||
| Optional communication format, baud rate | |||
| 4800/9600/19200/384000 | |||
| Default value:9600 | |||
Packaging & Delivery
Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
Transportation | Routine |
| By car | 3 hours from Shanghai to Yixing |
| By high speed railway | 2 hour from Shanghai(or Shanghai Hongqiao) railway station to YiXing railway station,then we will pick you up.It will take 10 mins by car from Yixing railway station to our company. |
