SW9800-V5/V7
Weighing display controller (Stainless Steel Shell)
Application: Can be used for various high-precision electronic platform scales and truck scales
Main Technical Index
- Range of Input Signal: -10~+28mV
- A/D Conversion: 24-bit Sigma-Delta A/D Conversion
- A/D Sampling Frequency: 38.400 kHz
- Nonlinearity: ≤0.0015% F.S.
- Gain Error Drift: 1 ppm/℃
- Minimum Resolution: 0.1uV/d
- Display Number of Division: ≤100000
- Supply Voltage: DC10V/350mA (can connect 16 sensors)
- Operating Temperature: -10~+40℃
- Storage Temperature: -40~+85℃
- Relative Humidity: ≤90%R.H
- Power Supply: AC187~242V, 49~51Hz
- Power Dissipation: 10W
- External Dimension: 300×200×120mm
- Weight: 3.2kg
Main Performance
- The high accuracy weighing measuring appliance, demonstrated that the number of division is highest may achieve 100000
- Stainless steel outer covering, the resistance to interference is good, and more durable
- 6-bit VFD (Vacuum Fluorescent Display)
- Be capable of displaying mill volt signal, and easy to detect whether the sensor is in good condition or not
- Super anti-vibrates the filter, Filtering Progression Adjustment (Grade 1-4) and the T3.0 of Stabilization Control Procedure
- Sensor long-line compensatory function, and The sensor main line may longer
- A/D transformation uniformity is good, and No re-scaling is needed during instrument changing
- The measuring range establishment uses the password locking and overload monitor, prevents the user overload weighing
- Automatic Switching in 3 Graduations
- Perpetual calendar clocks, not power failure influence
- Large capacity memory, may store reaches 1521 group of weighing records
- 3-level Timing Power Off
- 20mA Current Loop and RS-232C or RS-485(optional) Serial Communication Interface
- Baud Rate 1200/2400/4800/9600 (optional)
- The standard parallel printer connection, may match meets each kind of needle type printer
Package and Delivery
DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
