Home > Instruments & Meters > Weighing & Measuring Apparatus > Electronic Scale > Wall Mounted Wireless Weight Indicator

Wall Mounted Wireless Weight Indicator

Name: Wall Mounted Wireless Weight Indicator
Brand: SILVANUS
SKU: 110205183
Availability: InStock

Wall Mounted Wireless Weight Indicator thumbnail-1

Wall Mounted Wireless Weight Indicator photo-1

US$ 800 - 1,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

SILVANUS

Model Number:

SW-5000FS

Contact Supplier Request Quote Chat Now

Silvanus Electric Manufacture (Yixing) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name SILVANUS

Model Number SW-5000FS

Type Other, weighing indicator

Power Supply DC5V±0.3V

Display Type LED

SW – 5000FS Wireless weighing indicator

Product Introduction

SW-5000F/S wireless transmission system is a specially developed weight transmitter which have both setting control technology and digital transmitting functions. Widely used in moveable transmisson system like crane scale, vehicle scale, large rotary table.The receiving device transfer data to computer management and control system, convenient to meet of production control.

Product Feature

1.Technical Parameters
Linearity:	0.01%F.S
Input Sensitivity:	0.25µv/d
Rang of input signal:	0.1mV~20mV
A/D conversion speed:	100times/sec
A/D conversion code:	1 million code
Display division:	≤60000 code
Temperature Effect On Zero:	≤0.2µV/℃
Full temperature effect:	≤10ppm/℃
Load cell exciting Voltage:	DC5V±0.3V
Most exciting current:	200mA

2.Communication interface

One road radio interface Signal types:Standard RS-232 Baud rate:1200

3.Display

Main display :5 bits red ,0.8 inch LED.

Slave display: 6 bits red,0.5inch LED,Display AD value.

Indicator light:8 pcs

4.General requirements and usage environment

Environment temperture	0~40℃
Relative temperature	40℃(20~90)%RH
atmospheric pressure	86~106 Kpa
Supply Voltage	AC220
power frequency	50±1Hz
No corrosive gases or fluid around
Keep away from strong electromagnetic field
Keep away from high voltage power line and the high frequency equipment.
Warm up time	30min
Power consumption	≤10W
Weight:	2kg

5.Dimension and installation

Size:180*260*95 (mm)

Instal:wall mounted installation dimension 150*273(mm)

Packaging & Delivery

PACKAGE:

Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.

Our Company:

Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
