Specifications
1CH CIF Video Server with SATA HDD*H264&MJPG,SD,FTP,Audio,Alarm IP Video Server
*Free CMS,Mobile phone View,3G Video Server
1CH CIF Video Server with SATA HDD
*H264&MJPG,SD,FTP,Audio,Alarm IP Video Server
*Free CMS,Mobile phone View,3G Video Server
*Video Resolution: D1/Half-D1/CIF/QCIF
*HDD storage, 2TB maximum
*802.11b/g WIFI network (optional)
*3G (WCDMA/CDMA2000/TD-SCDMA) optional
KD-DS101CT |
Wired,1 channel, CIF |
Video Input |
1/2/4 channel composite video, PAL or NTSC BNC interface,1.0Vp-p,impedance 75Ohms |
Video compression |
H.264 Main Profile @Level 3 / MJPEG |
Dual-Streaming |
H.264/ MJPEG option |
Video Definition |
PAL: 352*288 (CIF), 704*288 (2CIF), 704*576 (D1); |
NTSC: 352*240 (CIF), 704*240 (2CIF), 704*480 (D1) | |
Video Parameters |
Brightness, Hue, Contrast, Saturation, Image quality. |
Streaming Format |
Optional Video Streaming or Audio &Video composite Streaming |
Video Frame Rate |
PAL: 1-25 frames/second ; NTSC:1-30 frames/second |
Video Bit rate |
32Kbps~16Mbps |
Video Output |
1 compound video, PAL or NTSC; BNC, level: 1.0Vp-p, impedance: 75Ω, |
Audio Compression |
G.726, G711, ADPCM |
Audio Input |
1/2/4 channel, RCA port, liner input, Impedance:1KOhms |
Audio Output |
1channel,RCA port, linear output |
Audio talk-back input |
1 channel ,MIC port |
Overlaid Caption |
Channel, Date, Bit rate. position adjustable |
Communication Interface |
1 10M/100M self-adapting Ethernet port, RS485 port, RS232 port Built-in some high-speed protocols and decoding protocols. Support public protocols. Support CDMA, GPRS mobile network. Supports 802.11b/g protocol, 2.4GHz, maximum wireless distance can be 100 meters, Supports WEP,WPA,WPA2(support wireless model) |
Storage interface |
Built-in standard SATA port for HDD. Support SD card storage and snapshot, SD2.0 standard. (Max 32G SD card), Support FTP server. |
Supports smart mobile monitor that is based on Windows Mobile, Symbian and iPhone platforms | |
Alarm Input |
4 channel on/off input, supporting NO (normally open) or NC (normally close) sense. |
Alarm Output |
4 channel on/off output,120VAC 1A/24VDC 1A |
Alarm Message |
Sending alarm message by Email. |
Input Power Supply |
DC 12V,3A |
Maximum Power |
Less than 15W |
Operating Temperature |
-10 ~ +55°C |
Operating Humidity |
RH90%MAX |
Dimension |
33Cm(L) * 20Cm(W)* 4.8Cm(H) |
Net weight |
1.82kg |
