Programmable Constant Temperature and Humidity Chamber
Application:
Programmable constant temperature and humidity chamber is also called environment testing machine, used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.
Programmable Constant Temperature and Humidity Chamber Features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips . Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for viewing sample under test, with interior light.
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5. French Tecumseh is used as compressor, with environment friendly refrigeration R23 or R404A.
6. LCD display screen, capable of displaying the measured value as well as the set value and time.
7. The control unit has the functions of multiples segment program editing, with quick or ramp rates control of temperature and humidity.
8. Casters are provided for ease of mobility, with strong positioning screws.
Programmable Constant Temperature and Humidity Chamber Technical Parameters:
Model |
TH-80(A~F) |
TH-150(A~F) |
TH-225(A~F) |
TH-408(A~F) |
TH-800(A~F) |
TH-1000(A~F) |
Internal Dimension mm |
400x500x400 |
500x600x500 |
600x750x500 |
600x850x800 |
1000x1000x800 |
1000x1000x1000 |
Enternal Dimension mm |
950x1650x950 |
1050x1750x1050 |
1200x1900x1150 |
1200x1950x1350 |
1600x2000x1450 |
1600x2100x1450 |
Temperature Range |
Low Temperature(A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C) High Temperature 150°C |
|||||
Humidity Range |
20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optiona , need Dehumidifier) |
|||||
Indication relolution / Distribution uniformity |
0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H. |
|||||
Control Accuracy |
±0.5°C; ±2.5% R.H. |
|||||
Temperature Rising / Falling Velocity |
Temperature rising approx. 0.1~3.0°C/min |
|||||
Material |
Interior material is SUS 304# stainless steel, exterior is stainless steel or SEE cold-rolled steel with paint coated. |
|||||
Insulation Material |
Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials |
|||||
Cooling System |
Wind cooling or water cooling, (single segment compressor-40°C, double segment compressor -70°C) |
|||||
Protection Devices |
Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection |
|||||
Optional Accessories |
Inner door with operation hole , Recorder, Water Purifier, Dehumidifier |
|||||
Compressor |
French Tecumseh Brand, Germany Bizer Brand |
|||||
Power |
AC220V 1-3 lines, 50/60HZ , AC380V 3- 5 lines , 50/60HZ |
|||||
Weight (Kg) |
150 |
180 |
250 |
320 |
400 |
450 |
Warranty: one year free warranty for whole set machine,lifelong time maintainance.
After-sale service: feedback within 2 hours after get the call.
Service:OEM service,Design service,Buyer lable service.
Extension functions:
1 Environmental test chamber is designed to do high temperature & high humidity, high/low temperature, or temperature cycling test,etc, for quality inspection and assessing their quality reliability and use life.
2 Temperature & Humidity Test Chambers simulate a full range of temperature and humidity conditions.These chambers are designed for ease-of-use, reliability and performance and include many user-friendly features standard with your purchase for the best value in the industry.
3 Programmable constant temperature and humidity test chamber are able to provide rapid product temperature change rates and use varying levels of relative humidity to locate design problems prior to shipping your products, improving product quality and reliability.
