Environmental Constant Temperature and Humidity Test Chamber application:
Environmental Constant Temperature and Humidity Test Chamber is used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.
Environmental Constant Temperature and Humidity Test Chamber features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips,plane handle
2. Rectangular double-glassed watching window for the observation of the test production during the testing process. The window is equipped with sweat-proof electrical heating device that can prevent water steam from condensing into droplets, and with high brightness PL fluorescent bulbs to provide light inside the box.
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5. The French Tecumseh brand is used for the circulation system of the compressor, capable of removing the lubricant between the condensation pipes and capillaries. The environment-protecting coolant is used for the whole series (R23, R404A)
6. LCD display screen, capable of displaying the measured value as well as the set value and time.
7. The control unit has the functions of multiples segment program editing, and of quick or slope control of temperature and humidity.
8. Inserted mobile pulley, convenient for movement an relocation, with strong positioning screws.
Environmental Constant Temperature and Humidity Test Chamber technical parameters:
Model |
TH-80(A~F) |
TH-150(A~F) |
TH-225(A~F) |
TH-408(A~F) |
TH-800(A~F) |
TH-1000(A~F) |
|
Interior Dimension WxHxD (mm) |
400x500x400 |
500x600x500 |
600x750x500 |
600x850x800 |
1000x1000x800 |
1000x1000x1000 |
|
Exterior Dimension WxHxD (mm) |
950x1650x950 |
1050x1750x1050 |
1200x1900x1150 |
1200x1950x1350 |
1600x2000x1450 |
1600x2100x1450 |
Temperature Range |
Low Temperature(A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C) High Temperature 150°C |
|||||
Humidity Range |
20%~98%R.H.(10%-98% R.H. / 5%-98% R.H.,is a special optional condition, need Dehumidifier) |
|||||
Indication Resolution / Distribution Uniformity of temperature and humidity |
0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H. |
|||||
|
Control Accuracy of Temperature and Humidity |
±0.5°C; ±2.5% R.H. |
|||||
|
Temperature Humidity Control Chart |
|
|||||
|
Temperature Rising /Falling Velocity |
Temperature rising approx. 0.1~3.0°C/min;temperature falling approx. 0.1~1.5°C/min; ( The Falling Speed Rate Min.1.5°C per minute is a special optional condition) |
|||||
|
Inner and Outer Material |
Material of the inner box is SUS 304# stainless steel, of the outer box is stainless steel or SEE cold-rolled steel with paint coated. |
|||||
Insulation Material |
Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials |
|||||
Cooling System |
Wind cooledor water cooled; single segment compressor for -40°C, double segment compressor for -70°C |
|||||
Protection Devices |
Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection |
|||||
Optional Accessories |
Inner door with operation hole , Recorder, Water Purifier, Dehumidifier |
|||||
Compressor |
French Tecumseh, Germany Bizer |
|||||
Power |
AC220V AC380V |
|||||
Weight (Kg) |
150 |
180 |
250 |
320 |
400 |
450 |
