Dual dust and sand chamber application:
Dual dust and sand chamber is used for all kinds of automobile parts, such as, automobile lamps, meter, safe belt, seat regulator, dirt-proof boot of electrical appliance, lockers etc.
Dual dust and sand chamber features:
1. Strong spray dust device, can operate independently for No.1 floating dust, No.2 floating dustt,No.3 floating dust on the gauge panel.
2. Vibration device; spray dust’s density can be the same every time.
3. Precision collection for dust concentration, Can reduce improper operation mistake
4. Control system: connected with and monitored by computer
5. Convenient design for dust cleaning.
6. Synchronous resonance function to ensure the uniformity of dust concentration
Dual dust and sand chamber technical parameters:
Model |
DT-F1 |
DT-F2 |
DT-F3 |
DT-C1 |
DT-C2 |
Remark |
F for floating dust |
C for cyclone dust |
|||
|
Concentration of Sand and Dust |
F1: 60000mg/m3
|
F2: 3000mg/m3
|
F3: 100mg/m3 |
C1: 5000mg/ m3, 5m/s |
C2: 100mg/ m3, 10m/s |
|
Interior Dimension WxHxD (mm) |
1000x1000x1000 |
1000x1000x1000 |
|||
|
Exterior Dimension WxHxD (mm) |
1600x1800x1300 |
1650x1850x1450 |
|||
Temperature Range |
RT(25°C±15°C), or lab temperature |
RT(25°C±15°C), or lab temperature |
|||
Humidity Range |
35 to 90% R.H., or lab humidity |
35 to 90% R.H., or lab humidity |
|||
|
Talcum Powder Dosage(Kg/m ²) |
2 to 4 |
||||
|
Metal Net Mesh Standard Diameter(μm) |
50 |
||||
|
Diameter Between Metal Wires(μm) |
75 |
||||
|
Powder Spray & Dust Fall Mode |
1. Dust fall freely: centrifugal fan to blow the sand or dust to the 1/5 of roof 2. Blow the sand or dust: pressure spray dust from the bottom, multi-steps pressure adjustable |
||||
Test Standard |
Meet JIS, ISO, IEC60529,DIN40050,GB2423 test standard |
||||
Power |
AC 220V |
||||
