Standard Climatic and Dust Test Chamber

Standard Climatic and Dust Test Chamber thumbnail-1
Standard Climatic and Dust Test Chamber photo-1
US$ 1,000 - 2,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ASLi
Model Number:
DT Seires
Contact Supplier Request Quote Chat Now
Dongguan ASLi Test Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ANY CHINESE MAIN PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ASLi
Model Number DT Seires
Power Other, Electronic, AC 220V
Usage Universal Testing Machine

Standard Climatic and Dust Test Chamber Application:

It is used  for all kinds of automobile parts, such as, automobile lamps, meter, safe belt, seat regulator, dirty proof boot of electrical appliance, lockers etc.



Standard Climatic and Dust Test Chamber Features:

1. Strong spray dust device

2. Vibration device:spray dust’s density can be the same every time.

3. Precision collection for dust concentration

4.Can reduce improper operation mistake.

5. Meet DIN, IEC, GB, ISO, JIS standard.

6. Control system: connected with and monitored by computer.

7. Convenient design for dust cleaning.

8. Synchronous resonance function to ensure the uniformity of dust concentration.



Standard Climatic and Dust Test Chamber Technical parameters:

1. Model: DT-F1 DT-F2 DT-F3 DT-C1 DT-C2

2. Remark: F for floating dust; C for cyclone dust;

3. Concentration of Sand and Dust: F1:  60000mg/m3; F2:  3000mg/m3; F3:  100mg/m3; C1:

5000mg/ m3, 5m/s; C2:100mg/ m3, 10m/s

4. Internal Dimension WxHxD (mm): 1000x1000x1000 1000x1000x1000

5. External Dimension WxHxD (mm): 1600x1800x1300 1650x1850x1450

6. Temperature Range: RT(25°C±15°C), or lab temperature; RT(25°C±15°C), or lab temperature

7. Humidity Range: 35~90% R.H., or lab humidity; 35~90% R.H., or lab humidity

8.Talcum Powder Dosage(Kg/m ²): 2 ~4

9. Metal Net Mesh Standard Diameter(μm): 50

10. Diameter Between Metal Wires(μm): 75

11. Powder Spray & Dust Fall Mode:

A. Dust fall freely: adopt centrifugal fan to blow the sand or dust to the 1/5 of roof, fall freely.

B. Blow the sand or dust: pressure spray dust from the bottom, multi-steps pressure adjustable

12. Test Standard: Meet JIS, ISO, IEC60529, DIN40050, GB2423 test standard

13. Power: AC 220V(±10%) 50/60HZ ;
