non-standard customized sand blast chamber
1. Application:
Sand chamber is used for all kinds of automobile parts, such as, automobile lamps, meter, safe belt, seat regulator, dirt-proof boot of electrical appliance, lockers etc.
2. Features:
1. Strong spray dust device, can operate independently for No.1 floating dust, No.2 floating dust,No.3 floating dust on the gauge panel.
2. Vibration device; spray dust’s density can be the same every time.
3. Precision collection for dust concentration, Can reduce improper operation mistake.
4. Meet DIN, IEC, GB, ISO, JIS standard
5. Control system: connected with and monitored by computer
6. Convenient design for dust cleaning.
7. Synchronous resonance function to ensure the uniformity of dust concentration
3. Technical parameters:
Model |
DT-F1 |
DT-F2 |
DT-F3 |
DT-C1 |
DT-C2 |
Remark |
F for floating dust |
C for cyclone dust |
|||
Concentration of Sand and Dust |
F1: 60000mg/m3 |
F2: 3000mg/m3 |
F3: 100mg/m3 |
C1:5000mg/ m3, 5m/s |
C2:100mg/ m3, 10m/s |
Interior Dimension WxHxD (mm) |
1000x1000x1000 |
1000x1000x1000 |
|||
Exterior Dimension WxHxD (mm) |
1600x1800x1300 |
1650x1850x1450 |
|||
Temperature Range |
RT(25°C±15°C), or lab temperature |
RT(25°C±15°C), or lab temperature |
|||
Humidity Range |
35 to 90% R.H., or lab humidity |
35 to 90% R.H., or lab humidity |
|||
Talcum Powder Dosage(Kg/m ²) |
2 to 4 |
||||
Metal Net Mesh Standard Diameter(μm) |
50 |
||||
Diameter Between Metal Wires(μm) |
75 |
||||
Powder Spray & Dust Fall Mode |
1. Dust fall freely: centrifugal fan to blow the sand or dust to the 1/5 of roof |
||||
Test Standard |
Meet JIS, ISO, IEC60529,DIN40050,GB2423 test standard |
||||
Power |
AC 220V |
||||
4. Warranty: one year free warranty for whole set machine,lifelong time maintainance.
5. After-sale service: feedback within 2 hours after get the call.
6. Service: OEM service,Design service,Buyer lable service.
7. More pictures for non-standard customized sand blast chamber:
