IP rate dustproof test chamber
Application:
It is used for all kinds of automobile parts, such as, automobile lamps, meter, safe belt, seat regulator, dirty proof boot of electrical appliance, lockers etc.
Features:
1. Strong spray device
2. Vibration device:spray dust’s density has good uniformity.
3. Precision collection for dust concentration
4. Control system: connected with and monitored by computer
5. Convenient design for dust cleaning
6. Synchronous resonance function to ensure the uniformity of dust concentration
7.Can reduce improper operation mistake
8. Meet DIN, IEC, GB, ISO, JIS standard
Technical parameters:
1. Model: DT-F1 DT-F2 DT-F3 DT-C1 DT-C2
2. Remark: F for floating dust; C for cyclone dust;
3. Concentration of Sand and Dust: F1: 60000mg/m3; F2: 3000mg/m3; F3: 100mg/m3; C1:5000mg/ m3, 5m/s; C2:100mg/ m3, 10m/s
4. Interior Size WxHxD (mm): 1000x1000x1000 1000x1000x1000
5. Exterior Size WxHxD (mm): 1600x1800x1300 1650x1850x1450
6. Temp. Range: RT(25°C±15°C), or lab tep.; RT(25°C±15°C), or lab temp.
7. Humidity Range: 35~90% R.H., or lab humidity; 35~90% R.H., or lab humidity
8.Talcum Powder Dosage(Kg/m ²): 2 ~4
9. Metal Net Mesh Standard Diameter(μm): 50
10. Diameter Between Metal Wires(μm): 75
11. Powder Spray & Dust Fall Mode:
A. Dust fall freely: adopt centrifugal fan to blow the sand or dust to the 1/5 of roof, fall freely.
B. Blow the sand or dust: pressure spray dust from the bottom, multi-steps pressure adjustable
12. Test Standard: Meet JIS, ISO, IEC60529, DIN40050, GB2423 test standard
13. Power: AC 220V 50/60HZ ;
Standard Climatic and Dust Test Chamber More pictures:
