Rail Type Gas Cutter For Profile Gas Cutting Machine

Name: Rail Type Gas Cutter For Profile Gas Cutting Machine
Brand: YILANG
SKU: 110153389
Availability: InStock

US$ 440 - 500 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

China

Brand Name:

YILANG

Nanning ChuanJun Welding Hardware Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Nanning

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin China

Brand Name YILANG

Model Number CG2-150B

Voltage AC220/50

Dimension(L*W*H) 1190*335*870mm

Weight 61.5kG

Certification CE ISO9001

Warranty 1 Year

Product Description

Rail Type Gas Cutter For Profile Gas Cutting Machine

1.Controlled silicon speed, stable operation.

2.In the specified range can be cut according to the template of a variety of two-dimensional shape.

3.This machine is especially suitable for mass production of parts with the same shape.

4.Mainly used in shipbuilding, boiler, metallurgy and mechanical processing and other factories.

1..Lift wheel of arm :Release the screw of arm and adjust the wheel to make the arm unit assembly rise or fall	7.Cross moving bar:Measuring scale is set on the fracture of cross moving bar. You can adjust the sample plate horizontally according to scale
2.Power switch	8.Frame of sample plate: To fix the sample plate and adjust the height of sample plate
3.Outlet	9.Magnetic head
4.Hoses: There are four hoses: preheating, cutting, fuel gas and feeding gas for pressure switch	10.Speed regulating knob:Increase the speed if you revolve it along “0” to “10”
5.Screw at the bottom: Make the machine horizontal on steel plate	11.Direction regulating switch: To change the rotary direction of magnetic head.
6. Locking screw of arm cross moving bar: If the position of sample plate is settled, you can fix the cross moving bar on the arm with locking screw	12.Lifting hand wheel of torch
	13.Torch

Specification

1.Weight(Body)	:61.5 KG
2. Machine dimension	:1190mm×335mm×870mm
3.Speed control	:SCR
4.Power source	:220V 50HZ
5. Cutting speed	:50~750/mm/min
6. Cutting thickness	:5~100mm
7. The diameter of cutting circle.	:ø20~ø600mm
8. Length of cutting line.	:1200mm
9. Size of cutting rectangle.	:400mm×900mm, 450mm×750mm
10.Motor	:55/ZYT DC110V24W 3600r/min

Packaging & Shipping

Packing:

After quality testing,our products will be well packed.

1 First wrapped by plastic film

2 Then fixed by EPE foam

3 Carton box outside

1. Main body	1set
2. Standard torch unit assemblage	1set
3. Tip (acetylene 1 # 2 # 3# )	3pcs
4.Power wire	1pc
5. Specification sheets and certificate of qualification	1pc each
6. Gas-in connector	1set
Standard accessory
1.balance bar	2pcs
2.Heavy punch	1set
3.Sample plate of circle	1set
4.Angle-iron and connecting pipe(CG2-150BA)	1pc each
