G1610 100W CNC Laser Machine
Standard Features:
Working area: 1600x1000mm
Power: 100w
Laser tube type: 8000-10000hours, guarantee period is 8 months
Control mode: USB interface
File export Software: DSP5.3
Compatible file design software: Photoshop, Corel draw, AutoCAD, etc
Files Support:: bmp, plt, eps, pes, jpg, ai etc.
Mechanical orbits: Taiwan brand orbits, with high precision and long life time.
Motor and driver type: Step motors and step drivers
Cooling type: Water pump
Table type: Honycomb table or strip table
Options:
- RECI long life time co2 laser tube, life time is 8000 hours, guarantee period is 8 months.
- CW3000 chiller with warning system (< or =80w laser tube can choose this chiller), CW5000
- (> or = 100w better to choose this chiller)
- Japan servo motors and drivers
- Auto focus function
- Auto lifting table
- Auto lifting table + rotary clamp (can work on cylinder materials, like cup, pencil and so on)
- Laser red point (to know where the work will start from)
- Auto lifting table+ rotary clamp
Application:
Applicable materials: wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic,
glass and other nonmetal materials
Applicable industries: advertisement, gift, shoes, toys, computers, garments, model cutting, building,
packaging, paper industry
Technical Parameter:
Laser power : |
100W (optional) |
Laser type: |
CO2 glass tube |
Power supply: |
AC220±10, 50 HZ/ or AC110±10, 50 HZ |
Working area: |
1600mmx1000mm |
Max moving speed: |
1500mm/s |
Worktable: |
Honey comb worktable (mainly engraving and small pieces cutting) /knife (engraving and cutting) /normal table (engraving) (optional) |
Locating precision: |
<0.01mm |
Min shaping character: |
Character:3x3mm,letter:2x2mm |
Operating temperature: |
5°C-35°C |
Working humidity |
5%-95%(without condensed water) |
Resolution ratio: |
4500dpi |
Control configuration: |
DSP5.3 |
Data transfer interface: |
USB(offline) |
System environment: |
WINDOWS 2000/WINDOWS XP/ windows 7 |
Cooling way: |
Water cooling and protection system |
Graphic format supported: |
The file which CorelDraw, Photoshop, AutoCAD can identify(BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,DXP,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX) etc. |
Compatible software |
CorelDraw, AutoCAD, Photoshop, laser cut software |
Cutting thickness |
0-20mm also (depends on different material) |
Color separation |
Separation of cutting up to 256 colors |
Sloping engraving |
Yes, slope can be designed discretionarily |
Cuts off the water supply the protection |
yes |
Whole machine dimension |
3050×1960×990 (mm) |
Gross weight |
650kgs |
packing |
Plywood case (veneer wood case for export) |
Optional parts |
1. longer time tube: 8000-10000hours life time tube. 2. Bigger power tubes (130w, 150w etc) 3. double-head or more heads 6. Cylinder rotary clamp (for cylinder materials working. Like cup, pen, bottles etc. Please note: this big working size table can’t add whole table with auto lifting table, only can add partial, please let us know the size you want to add if needed) 7. irregular rotary clamp 8. Ball screw 9. servo motor 10. Auto focus (usually need auto lifting table) 11. Auto feeding system etc. Note: Above are the main optionals, not all the machines can add above optionals, please contact us, we will give you suggestions, thanks. |
Packing List:
DEC |
Q’TY |
LASER MACHINE |
1 |
EXHAUST FAN |
1 |
AIR PIPE |
1 |
BLOWER |
1 |
RUBBER PIPE |
3 |
WATER COOLING EQUIPMENT |
1 |
COMMUNICATION CABLES |
3 |
POWER SUPPLY LINE |
1 |
SOFTDOG |
1 |
LASER TUBE |
1 |
LASER POWER SUPPLY |
1 |
LASER POWER SUPPLY CONTROL LINE |
1 |
LASER POWER LINE |
1 |
RESET SWITCH |
2 |
LOCK AND KEY |
3 |
VIDEO CD |
1 |
LASER TARGET |
1 |
FOCUS RULER |
1 |
LENS PAPER |
1 |
FOCUS LEN |
1 |
REFLECT MIRRORS |
3 |
USB INTERFACE |
1 |
USB data wire |
1 |
SOFTWARE |
1 |
USER MANUAL |
1 |
QUALITY CERTIFICATE |
1 |
GUARANTEE CARD |
1 |
machine photos:
samples:
Certificate:
Customer feedback:
Contact us:
Sales: MAQI
Tel: +86-531-88682639
Fax: +86-531-88682639/38
Skpe ID:Grace005
Web:
