Help CenterSemi-automatic Stretch Blow Molding Machine 1-4 Cavity
Related Products
-
Supply Automatic Bottle Blow Molding Machine Stretch Type 1000mlUS$ 30,000 - 80,000MOQ: 1 Set -
2000ml Pet Stretch Blow Molding Machine / Bottle Making PlantUS$ 30,000 - 80,000MOQ: 1 Set
-
PET Blow Molding/plastic Bottle Making/stretch Moulding MachineUS$ 30,000 - 80,000MOQ: 1 Set
-
200-1500ml Pet Bottle Mini Blow Moulding MachineUS$ 30,000 - 80,000MOQ: 1 Set
-
(BST-2500) Full Automatic Factory Blow Molding MachineUS$ 30,000 - 80,000MOQ: 1 Set
High quality of blowing machine adopt Europe design, easy to use and maintenance, low cost and high eficiency production. Semi-automatic Stretch Blow Molding Machine for 1-8cavity choose.
BST-3000A-III is high speed machine, low cost of production, easy to use and maintenance. We adopt Europe technology for our machine to get a high quality and stable machine. We use import sparepart such as Siemens PLC controlled system to get a stable computerized controller of the machine, switch from Germany and Cyliner and valve from Festo, Germany
All of our sparepart for the machine is standard part. So customer will be more easy to find and buy the sparepart. We also can send our engineer to your country to help you installation the machine.
For more information on Semi-automatic Stretch Blow Molding Machine, please feel free to contact us.
Process of blow molding
Specifications
Main machine (blowert + oven) |
Model type |
Tech data |
Product Spec |
Max. product volume(L/cav) |
20 |
Max. preform neck size(mm) |
200 |
|
Max. product diameter(mm) |
400 |
|
Max. product height (mm) |
600 |
|
Cavities |
1-4 (6cavity needs auto-loader) |
|
Blow molding part |
Die force (KN) |
150 |
Die stroke (mm) |
340 |
|
Max. mould size(mm) |
420*500 |
|
Mould thickness |
Adjustable |
|
Mould spacing(mm) |
500 |
|
Max. pulling stroke(mm) |
400 |
|
Operation pressure(Mpa) |
0.8-1.0 |
|
|
Operation air pressure consumption (1tr/min) |
560 |
|
Blow pressure(Mpa) |
1.2-2.8 |
|
Blow air pressure consumption (1tr/min) |
650 |
|
Output(pcs/h) |
600-900 |
|
Machine size(LxWxH)(m) |
2.18*0.77*1.96 |
|
Machine weight(KG) |
1000 |
|
Oven |
Temperature grade(rate) |
8 |
Heating time(S) |
90-200 |
|
Voltage(V) |
220 or as your request |
|
Frequency(HZ) |
50/60 |
|
Total power(KW) |
15-40 |
|
Oven Size (LxWxH) |
2.37*0.68*1.65 |
|
Oven weight (KG) |
380 |
Pneumatic parts | |||
Item |
Cylinder |
High pressure air valve |
Low pressure air valve |
Brand |
AIRTAC |
AIRTAC |
AIRTAC |
Description |
Moving smoothly Correctly High power |
Reversing precisely No retention |
Reversing precisely No retention |
Detail photos
About us
U TECH MACHINE CO., LTD is committing to manufacturing pet blow molding machinery , water & beverage filling, labeling and packing machine with 15 years experience. All machines are totally new with two years warranty. We are providing high quality Semi-automatic Stretch Blow Molding Machine as well.
