Fully Automatic Stretch Blow Molding Machine
- Automatic perform input and ready bottle output system.
- Machine adopt with the overall structure of super-standard anti-vibration design, high-speed operation state of the machine will shake down to a minimum.
- Machine adopts modular assembly method, greatly decrease the local amendments due to technological improvements when the machine is on processing.
- The structure of machine oven adopt the international most advanced energy-saving technology of infrared radiation heating, temperature control with automatic negative feedback, closed-loop regulation model.
- Automation controlling item adopts international high-end computer system, heating, collecting and measuring perform temperature with simulation input and output module.
- Man-machine interface displays current production situation, available for on line switching, parameter modification and production accounting, with automatic alarm, automatic fault detection and diagnose.
- Storing more than 7 kinds specification for making bottle.
- Adopt latest international air pneumatic.
- In order to save air, we choose high pressure blowing exhaust recovery system, which can save energy by 10-15%.
Technical Parameter:
TYPE |
ITEM |
BST-2000 |
BST-4000 |
BST-6000 |
BST-8000 |
CONTAINER |
Theoretical output |
2000 |
4000 |
6000 |
8000 |
ntainer volume |
2L |
2L |
0.7L |
0.7L |
|
Max.neck diameter |
38mm |
38mm |
38mm |
38mm |
|
ntainer diameter |
105mm |
105mm |
70mm |
70mm |
|
ntainer height |
335mm |
335mm |
250mm |
250mm |
|
Max.perform height |
150mm |
150mm |
130mm |
130mm |
|
Number of cavity |
3 |
4 |
6 |
8 |
|
ELECTRICAL SYSTEM |
Motor power |
3KW |
3KW |
3KW |
3KW |
Heating power |
30KW |
33KW |
35KW |
45KW |
|
Actual total power |
33KW |
36KW |
38KW |
48KW |
|
AIR SYSTEM |
Operataiting low pressure |
0.7Mpa |
0.7Mpa |
0.8–1.0Mpa |
0.8–1.0Mpa |
Low pressure consuming |
0.6-0.8m3/min |
0.6-0.9m3/min |
0.7-0.9m3/min |
0.7-1.0m3/min |
|
Blowing pressure |
3.5Mpa |
3.5Mpa |
3.5Mpa |
3.5Mpa |
|
High pressure consuming |
2-3m3/min |
3-4m3/min |
4-5m3/min |
5-6m3/min |
|
CHILLER WHATER |
Operating pressure |
0.3-0.5Mpa |
0.3-0.5Mpa |
0.3-0.5Mpa |
0.3-0.5Mpa |
Temperature |
–10°C~55°C |
–10°C~55°C |
–10°C~55°C |
–10°C~55°C |
|
Flow rater |
40L/min |
40L/min |
50L/min |
70L/min |
|
MACHINE |
Machine dimension |
3.5x2x2.2m |
4x2x2.2m |
4.9x2.15x2.2m |
5.5x2.2x2.2m |
Machine weight |
4200Kg |
4800Kg |
5000Kg |
5800Kg |
Fully Automatic Stretch Blow Molding Machine
What service U Tech Machine Co.,Ltd can offer you ?
• Well-trained & experienced staff are to answer all your inquiries in English and Chinese
• 24 hours for engineer response (all services part 5days in customer hand by Intl' courier).
• 2 Years guarantee
• Your business relationship with us will be confidential to any third party.
• Good after-sle service offered, please get back to us if you got any questions.
Fully Automatic Stretch Blow Molding Machine
Q1:Are you a trading company or a manufactory?
A1:We are a manufactory,can give u best service .
Q2:What’s your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 2 years guarantee . we will give u spare part free in 2 years
Q3:When can I get my machine after I paid?
A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives?
A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q5:How about the spare parts?
A5:After we deal down all the things , we will offer you a spare parts list for your reference.
